28-EN
Adjusting the Sound Operation
MODE/Audio Control
f UP
g DN
DHE Preset buttons (1 through 6)DSP
Selecting DHE Mode
Using digital signal processing technology, DHE
(Digital Harmonics Enhancer) operates on harmonic
components which determine tone and coloration of
the musical instruments. The process operates
independently on individual frequency bands, so each
instrument or vocal will be distinct. Play back clarity is
enhanced to compensate for road noises which would
normally detract from the listener’s enjoyment.
1 Press the DHE button to activate the DHE
selecting mode. The display flashes.
2 Press the f UP button to select the desired
mode.
BASS MODE 1 (DHE 1):
Reproduces tight bass sound.
BASS MODE 2 (DHE 2): Reproduces ample volume
bass sound.
BASS MODE 3 (DHE 3): Reproduces bass sound
echoing in the core of your car.
VOCAL MODE (DHE4): Reproduces vocal sounds
more clearly.
ALL MODE (DHE5): Reproduces a well-balanced and
clear sound for all music genres.
NON EFFECT (OFF)
NOTE
If you press the g DN button, the display scrolls in
reverse sequence.
Selecting directly
Select the desired button (1 through 6).
[1] : BASS MODE1 [4] : VOCAL MODE
[2] : BASS MODE2 [5] : ALL MODE
[3] : BASS MODE3 [6] : NON EFFECT (OFF)
3 When the setting is complete, press the DHE
button to return to normal mode.
NOTE
This function is inoperable when DEFEAT is ON (refer
to page 9).
→ BASS MODE1 ←→ BASS MODE2 ←→ BASS MODE3 ←
→ NON EFFECT ←→ ALL MODE ←→ VOCAL MODE ←
Equalizer Presets
3 typical equalizer settings are preset at the
factory for a variety of musical source material.
1 Press the DSP button and select the EQ mode.
The mode will change every time the button is
pressed.
2 Press either the g DN button or the f UP
button.
• With each press of the button, the equalizer
mode will display the selected equalizer
characteristic.
FLAT: Flat frequency
POPS: Suppress midrange
ROCK:Emphasize lows and highs
NEWS:Boost midrange and suppress highs
and lows
Selecting directly
Select the desired button (1 through 4).
[1] : FLAT (OFF) [3] : ROCK
[2] : POPS [4] : NEWS
3 When the setting is complete, press the DHE
button to select OFF, and return to normal mode.
NOTE
This function is inoperable when DEFEAT is ON (refer
to page 9).
→ EQ ←→ EQ MEMORY ←→ LPS ←→ OFF ←
→ FLAT (OFF) ←→ POPS ←→ ROCK ←→ NEWS ←
→ EQ ←→ EQ MEMORY ←→ LPS ←→ OFF ←
