11-EN
Sound Setting
Adjusting Balance (Between Left and Right)/
Fader (Between Front and Rear)/Defeat
1
Press MODE (Rotary encoder) repeatedly to
choose the desired mode.
Each press changes the modes as follows:
SUBWOOFER*
1
→ BALANCE → FADER → DEFEAT →
VOLUME → SUBWOOFER*
1
Subwoofer : 0 ~ +15
Balance : L15 ~ R15
Fader : R15 ~ F15
Defeat : ON/OFF
Volume : 0 ~ 35
• If the MODE (Rotary encoder) is not pressed within 5 seconds
after selecting the BALANCE, FADER, DEFEAT or SUBWOOFER
mode, the unit automatically returns to normal mode.
*
1
When the subwoofer mode is set to OFF, its level cannot be
adjusted.
2
Turn the Rotary encoder until the desired sound
is obtained in each mode.
By setting Defeat ON, previously adjusted settings of
BASS and TREBLE will return to the factory defaults and
MX is turned off.
• Depending on the connected devices, some functions and display
indications do not work.
Setting the Bass Control
You can change the bass frequency emphasis to create your own tonal
preference.
1
Press CENTER f to select the Bass (bass center
frequency) Control mode.
BASS → TREBLE → normal mode → BASS
2-1
*2
Setting the bass center frequency:
Press g or f to select the desired bass center
frequency.
60Hz ↔ 80Hz ↔100Hz ↔ 200Hz ↔ 60Hz
The displayed bass frequency is emphasized.
.
2-2
*2
Setting the bass band width (Q-Factor):
Press BAND/TEL. to select the desired bass band
width.
Changes the boosted bass band width to wide or narrow.
A wide setting will boost a wide range of frequencies
above and below the center frequency. A narrower setting
will boost only frequencies near the center frequency.
2-3
Setting the bass level:
Turn the Rotary encoder to select the desired
bass level (–7~+7).
You can emphasize or weaken the bass frequency.
• If no buttons are pressed within 15 seconds, the bass control setting
will be turned off automatically.
• The bass level settings will be individually memorized for each
source (FM, AM, XM, CD, etc.) until the setting is changed. The
bass frequency and bass band width settings adjusted for one
source are effective for all other sources (FM, AM, XM, CD etc.).
• Depending on the connected devices, some functions and display
indications do not work. However, bass level is still adjustable if an
audio processor with the bass adjustment is connected.
• This function is inoperable when DEFEAT is set to ON.
*
2
Selecting any of the "Setting the Bass Type" (TYPE 1 through 3),
temporarily replaces the custom settings you have made above.
SOURCE/
POWER
g
f
BAND/
TEL.
MODE (Rotary encoder)
CENTER f
MX
→ B. Width1 → B. Width2→ B. Width3 → B. Width4
(Narrow)←→(Wide)
......................................
