11
OPERATION – BASIC
VOLUME KNOB/TONE CONTROLS
The Volume knob is a multifunction controller and handles the
Volume,Tone Controls, and Setup Options, see below.
To Control Volume
1. Turn the VOLUME knob (Volume Outside) clockwise to raise
volume.
2. Turn the VOLUME knob (Volume Outside) counter-clockwise
to lower volume.
To Adjust Tone Controls
1. Press the SELECT button (Volume Center) repeatedly to
cycle through SUM > BASS > TREBLE > BALANCE >
FADER > VOLUME.
2. Turn the VOLUME knob (Volume Outside) to increase,
clockwise, or decrease,counter-clockwise, the selected
function.
Source Tone Memory
Individual Bass & Treble settings are memorized for TUNER / CD PLAYER / CDCHANGER / AUX1.
NOTE:If no adjustment is made after 5 seconds, the MENU knob will revert to VOLUME mode.
SETUP OPTIONS
The list below shows the default Setup Options.The bracketed items are the
alternate options contained within each Setup Option.
Selecting Options
1. Press and hold the SELECT button (Volume Center) for about 1 second
until the first Option appears {LOCAL}.
2. Press the SELECT button (Volume Center) repeatedly to cycle through all
Setup Options.The first three options only affect the Tuner Mode.
3. To change an Option, press the UP or DN {Down} Button
( or ).
4. To store, wait 5 seconds and the Display will return to the last Mode shown.
• LOCAL [DX] — Adjusts the sensitivity of the tuner for rural conditions where
there are weak radio stations while Local adjusts the sensitivity for city conditions
where there are several strong radio stations.
• AMERICAS [EUR/AUST] — Allows tuning of frequencies available in
different parts of the world.
• P. PLAY [EJ MUTE] — Plays the Tuner after you eject a CD while Eject Mute
mutes the Tuner after you eject a CD.
• V/BAR ON [V/BAR OFF] — Displays the Volume Bar at the bottom of the Front Panel while
Volume Bar Off turns it off.
• INI VOL 15 — Sets the maximum Initial Volume when the unit turns on. Initial Volume sets point of
maximum volume when the unit is turned on. If the volume setting was lower than the initial volume
setting when the unit is turned off, then the lower volume will be used at turn on. If the volume setting
was higher than the initial volume setting, then the initial volume setting is used at turn on.This feature
prevents accidental high volume turn on as well as allows high volume settings to be retained in case
another preamplifier is the system’s main volume control.
• CONTRAST [VIEW 6] — Controls the view angle of the display. Allows adjustment for best visibility.
• SUM FLAT [80HZ] — Means third pair of RCA pre-outs is full-range while 80Hz means that the pre-
outs are crossed-over 80Hz low-pass for subwoofer use.
SEL
SEL
SEL
ENT
Press Center
Press & Hold Center
Turn Outside
Remote
Remote
