Hurricane 9200/S ADSL Ethernet Router User’s Guide
64
%""*,
Follow this procedure to add a PPP interface.
Note
If you need to use more than one PPP connection, you may be
able to create multiple PPP interfaces. The number and type of
PPP interfaces you can create depends on the lower-level ATM
VC interface type (LLC Mux or VC Mux), the Max Protocol setting
for the ATM VC interface, the PPP interface type you want to
create (PPPoA or PPPoE), and whether other WAN interface
types have already been configured (EoA or IPoA). Contact your
ISP for assistance.
1. From the PPP Configuration Page, click .
The PPP Interface – Add page displays:
Figure 19. PPP Interface – Add Page
2. Select a PPP interface name from the drop-down list, and
then enter or select data for each field.
The fields are defined in the tables on page 60 and 62.
3. Click .
A page displays to confirm your changes.
4. Click to return to the PPP page and view the new
interface in the table.
5. If you want the changes to be permanent, follow the
instructions on page 45 to commit them.
