9-EN
Playback
1
Press (OPEN).
The front panel will open.
2
Insert a disc with the label side facing up.
The disc will be pulled into the unit automatically.
Close the front panel manually and the “DISC IN” indicator
light up.
When a disc is already inserted, press SOURCE/ to
switch to the DISC mode.
TUNER XM RADIO/SIRIUS*
1
DISC iPod*
2
/AUX+*
3
BT AUDIO*
4
CHANGER*
5
TUNER
*
1
Only when XM Radio or SIRIUS Radio is connected.
*
2
Displayed only when the iPod is connected and AUX+ SETUP is set
to OFF, refer to “Setting the AUX+ SETUP Mode” (
page 18).
*
3
Displayed only when the AUX+ SETUP is set to ON, refer to “Setting
the AUX+ SETUP Mode” (
page 18).
*
4
Displayed only when BLUETOOTH IN is set to ADAPTE, refer to
“Setting the Bluetooth Connection” (
page 17).
*
5
Only when the CD changer is connected.
3
While playing back MP3/WMA/AAC, press or to
select the desired folder.
Pressing and holding or will change folders
continuously.
4
Press or to select the desired track (file).
Returning to the beginning of the current track (file):
Press .
Fast backward:
Press and hold .
Advancing to the beginning of the next track (file):
Press .
Fast forward:
Press and hold .
5
To pause playback, press / .
Pressing / again will resume playback.
6
After pressing (OPEN) to open the front panel,
press to eject the disc.
• Do not remove a CD during its eject cycle. Do not load more than
one disc at a time. A malfunction may result from doing either.
• If the CD does not eject, press and hold for at least 2 seconds.
• The “DISC IN” indicator lights up when a disc is inserted.
• The CD-player can play discs containing audio data, MP3 data,
WMA data and AAC data.
• “MP3” is displayed during MP3 playback.
• “WMA” is displayed during WMA playback.
• “AAC” is displayed during AAC playback.
• WMA format files that are protected by DRM (Digital Rights
Management), AAC format files that have been purchased from
iTunes Music Store and files that are copy-protected (copyright
protection) cannot be played back on this unit.
• The track display for MP3/WMA/AAC data playback is the file
numbers recorded on the disc.
• The playback time may not be correctly displayed when a VBR
(Variable Bit Rate) recorded file is played back.
MP3/WMA/AAC Play Display
The folder number and file number will be displayed as
described below.
• Press VIEW to switch the display. See “Displaying the Text”
(
page 15) for information about display switching.
Repeat Play
Press
4
to play back repeatedly the track being played.
The track (file) will be played repeatedly.
Press 4 again and select off to deactivate repeat play.
CD mode :
*
1
When a CD changer is connected.
• If RPT is set to ON during M.I.X. play in CD changer mode, M.I.X.
will apply to the current disc only.
CD/MP3/WMA/AAC
4 5
(OPEN)
F/SETUP
SOURCE/
/
Rotary encoder
/ENT
/ESC
VIEW
101 103
Folder number
display
File number
display
: Only a track is repeatedly played back.
: A disc is repeatedly played back.
