Alpine cda-9884 Car Stereo System User Manual



34-EN
Controlling CD Changer (Optional)
An optional 6-disc or 12-disc CD Changer may be connected to this unit
if it is Ai-NET compatible. With a CD Changer connected to the
Ai-NET input of this unit, the CD Changer will be controllable from
this unit.
Using the KCA-400C (Multi-Changer Switching device) or the
KCA-410C (Versatile Link Terminal) multiple changers can be
controlled by this unit.
See “Multi-Changer Selection (Optional)” on page 34 for selecting the
CD Changers.
The controls on this unit for CD Changer operation are operative
only when a CD Changer is connected.
The DVD changer (optional) is controllable from this unit as well as
the CD changer.
1
Press SOURCE/ to activate the CHANGER mode.
The source indicator varies depending on the connected source.
Press BAND to switch the Disc mode in the Changer mode.
2
Press F/SETUP to activate Disc Select mode.
3
Press the disc select buttons (1 through 6)
corresponding to one of the discs loaded in the CD
Changer.
The selected disc number appears in the display and
CD/MP3 playback starts.
After selecting the desired disc, you can operate in the same way as
for the CD player of this unit. For details, see the CD/MP3/WMA/
AAC section.
* When a 12-disc CD changer is connected.
Playing MP3 Files with the CD Changer
(Optional)
If you connect a changer compatible with MP3, you can play
CD-ROMs, CD-Rs, and CD-RWs containing MP3 files on this unit.
1
Press SOURCE/ to switch to the MP3 Changer
mode.
2
Press any one of the disc select buttons
(1 through 6) corresponding to one of the discs
loaded in the CD Changer.
3
To pause playback, press / .
Pressing / again will resume playback.
The unit can play discs containing both audio data and MP3 data.
For operating MP3 with an MP3 compatible CD Changer, refer to
“CD/MP3/WMA/AAC”
pages 9 to 12.
Multi-Changer Selection (Optional)
Alpine’s Ai-NET system will support up to 6 CD Changers. When
operating two or more changers, the KCA-400C (Multi-Changer
Switching device) must be used. If you use 1 Switching device, you can
connect up to 4 CD Changers. If you use 2 Switching devices, you can
connect up to 6 CD Changers. When using KCA-410C (Versatile Link
Terminal), you can connect two changers and two external outputs
(AUX).
1
Press SOURCE/ on this unit to activate the CD
Changer mode.
Alternatively, press SOURCE on the remote control
(RUE-4202) to activate the CD Changer mode.
2
Press BAND on this unit or the RUE-4202 to activate
the CD Changer Selection mode.
The CD Changer Selection mode remains active for a few
seconds.
3
Press BAND until the desired CD Changer indicator
appears on the display.
Alternatively press BAND on the Remote Control until the
desired changer indicator appears on the display.
If the selected CD Changer is not connected, the display will show
“NO CHANGER (No.)”.
To operate the selected changer, see “CD/MP3/WMA/AAC” (pages 9
to 12).
For further details about the external input (AUX) when using
KCA-410C, see “Setting the AUX Mode (V-Link)” on page 18.
Changer (Optional)
F/SETUP
/
BAND
SOURCE/
Select buttons
(1 through 6)
Disc Select Mode
(Disc No.1~6)
Disc Select Mode *
(Disc No.7~12)
RPT/M.I.X. Mode
Disc Select Mode
(Disc No.1~6)
SOURCE
BAND
