26-EN
Alpine introduces IMPRINT - the world’s first technology that
thoroughly eliminates in-car acoustic problems that normally degrade
sound quality, which enables us to experience music the way the artist
intended, refer to “About IMPRINT” (
page 33).
When the IMPRINT-BOX (PXA-H100) (sold separately) is connected
to this unit, MultEQ and the following sound adjustment can be
performed.
Changing MultEQ mode
MultEQ, developed by Audyssey Labs, automatically corrects the audio
for the listening environment. The system is optimized for selected
positions in the vehicle. To accomplish this, MultEQ must take
measurements of the vehicles response characteristics. For details on the
set up procedure, consult your authorized Alpine dealer.
Press and hold IMPRINT for at least 2 seconds to
change MultEQ mode.
MULTEQ OFF (Manual Mode) CURVE 1 (MultEQ-1)
CURVE 2 (MultEQ-2) MULTEQ OFF (Manual Mode)
• The Curve mode can be selected only when curve 1 and curve 2 are
stored.
• When using MultEQ, MEDIAXPANDER, MX LEV MODE,
CROSSOVER, T.CORR PARA, FACTORY’S EQ. SUBW PHASE,
SUBW CHANNEL, TW SETUP, EQ MODE, FILTER TYPE and
PARAMETER EQ/GRAPHIC EQ are set automaticall. They are no
longer user adjustable.
• When an external audio processor is connected, the MultEQ function
cannot be used.
Adjusting Subwoofer Level/Bass Level/
Treble Level/Fader (Between Front and
Rear)/Balance (Between Left and Right)
in MultEQ mode
You can change these settings to create your own preference in MultEQ
(CURVE 1 or CURVE 2) mode.
1
Press IMPRINT to activate the MultEQ adjustment
mode.
2
Turn the Rotary encoder to select the desired item,
and then press
/ENT.
SUBW LEVEL*
1
BASS LEVEL TREBLE LEVEL
FADER*
2
BALANCE SUBW LEVEL
3
Turn the Rotary encoder to change the setting as
below, and then press
/ENT.
Subwoofer level: 0 ~ +15
Bass level: -7~+7
Treble level: -7~+7
Fader: R15 ~ F15
Balance: L15 ~ R15
• If no operation is performed for 60 seconds after selecting the
SUBW LEVEL, BASS LEVEL, TREBLE LEVEL, FADER or
BALANCE mode the unit automatically returns to normal mode.
*
1
When the SUBWOOFER mode is set to OFF, its level cannot be
adjusted, and the SUBWOOFER ON/OFF cannot be adjusted in
MultEQ (CURVE 1 or CURVE 2) mode.
*
2
If you set the 2.2ch (3WAY)/4.2ch (FRONT/REAR/SUBW.) switch of
the Imprint-Box (PXA-H100) to 2.2ch (3WAY), you cannot adjust the
FADER mode. For details, refer to the Owner’s Manual of PXA-
H100.
• Depending on the connected devices, some functions and display
indications do not work.
IMPRINT Operation
(Optional)
BAND
SOURCE/
/ESC
Preset buttons
(1 through 6)
IMPRINT
Rotary encoder
/ENT
