18-EN
You can flexibly customize the unit to suit your own preferences and
usage. From the SETUP menu, Sound Customizing, Visual
Customizing, etc., can be modified.
1
Press and hold FUNC./SETUP for at least
2 seconds to activate the SETUP mode.
2
Turn the Rotary encoder to select the desired
SETUP menu, and then press
/ENT.
(e.g. Select SUBWOOFER)
BT IN*
1
CLOCK ADJ*
2
PLAY MODE INT MUTE*
3
AUX+ SETUP AUX+ NAME*
4
AUX NAME POWER IC
DEMO SUBWOOFER SUBW SYS*
5
SCROLLTYPE TEXT SCR FM-LEVEL REGIONAL*
6
PI SEEK*
7
AUTO CLOCK*
8
BT IN
*
1
Displayed only when INT MUTE is set to OFF, and the mode is set to
other than BT AUDIO.
*
2
Refer to “Setting the Time” (page 7).
*
3
Displayed only when BT IN is OFF.
*
4
Displayed only when AUX+ SETUP is ON.
*
5
Displayed only when SUBWOOFER is ON.
*
6
Refer to “Receiving RDS Regional (Local) Stations” (page 10).
*
7
Refer to “PI SEEK Setting” (page 10).
*
8
Refer to “Setting the Time to automatically Adjust” (page 10).
3
Turn the Rotary encoder to change the setting.
(e.g. Select SUBW ON or SUBW OFF.)
4
Press and hold FUNC./SETUP for at least 2
seconds to return to normal mode.
• Press /ESC to return to the previous mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
Setting the Bluetooth Connection (BT IN)
With Bluetooth technology, you can place a hands-free call by a
Bluetooth-equipped mobile phone.
If an optional Bluetooth INTERFACE (KCE-400BT) is connected,
make this setting when the Bluetooth function is used. For
details, refer to the Owner’s Manual of the optional Bluetooth
INTERFACE (KCE-400BT). Set ADAPTER when the Bluetooth
INTERFACE (KCE-400BT) is connected.
• The button can be used only when the optional Bluetooth
INTERFACE (KCE-400BT) is connected.
• If the mobile phone compatible with the Voice Dial function is
connected, the Voice Dial function can be used.
Adjusting Source Signal Levels
If the difference in volume level between the CD player and FM radio is
too great, adjust the FM signal level.
Subwoofer On and Off
When the subwoofer is on, perform the steps below to adjust the
subwoofer output level.
1 In the normal mode, press Rotary encoder (AUDIO)
repeatedly to select the SUBWOOFER mode.
2 Adjust the level by turning the Rotary encoder.
Setting the Subwoofer System
Select either SYS 1 or SYS 2 for the desired subwoofer effect.
SETUP
Use steps 1 to 4 to select one of the SETUP modes to
modify. See the applicable section below for details
about the selected SETUP item.
/ESC
Rotary encoder
/ENT
FUNC./SETUP
Bluetooth Setting
BT ADAPTER (Initial setting) / BT OFF
Sound Customizing
FM-LV HI (Initial setting) / FM-LV LOW
SUBW ON (Initial setting) / SUBW OFF
SUBWOOFER BASS LEVEL TRE LEVEL BALANCE
FADER DEFEAT VOLUME SUBWOOFER
SUBW SYS 1 (Initial setting) / SUBW SYS 2
SUBW SYS 1 : Subwoofer level changes according to the
main volume setting.
SUBW SYS 2 : Subwoofer level change is different from the
main volume setting. For example, even at
low volume settings, the subwoofer is still
audible.
