19-EN
Scroll Type Setting
Choose from two scrolling methods.
Select the type you prefer.
Scroll Setting (TEXT SCR)
This CD player can scroll the disc and track names recorded on
CD-TEXT discs, as well as the text information of MP3/WMA/AAC
files, folder names and tags.
• The unit scrolls CD text names, folder names, file names or tag
display.
Demonstration
This unit has a demonstration feature for the display.
• To quit Demo mode, set to DEMO OFF.
Playing MP3 Data (PLAY MODE)
This unit can play back CDs containing both CD and MP3/WMA/AAC
data (created in Enhanced CD (CD Extra) format). However, in some
situations, playback of an enhanced CD may be difficult. In this case,
you can select playback of a single session only, containing the CD data.
When a disc contains both CD and MP3/WMA/AAC data, playback
starts from the CD data portion of the disc.
• Perform this setting before inserting a disc. If a disc has already been
inserted, remove it first.
Turning Mute Mode On/Off (INT MUTE)
If a device having the interrupt feature is connected, audio will be
automatically muted whenever the interrupt signal is received from the
device.
Connecting to an External Amplifier (POWER IC)
When an external amplifier is connected, sound quality can be improved
by stopping the power supply of the built-in amplifier.
Visual Customizing
SCR TYPE1 / SCR TYPE2 (Initial setting)
SCR TYPE1 : The characters scroll from right to left, a
single character at a time.
SCR TYPE2 : Words are built up from left to right, a single
character at a time. When the display is filled,
it is cleared and the remaining words are
displayed the same way until all words of the
title have been shown.
SCR AUTO / SCR MANU (Initial setting)
SCR AUTO : The CD text information, the text information of
folder and file names, and the tags are
scrolled automatically.
SCR MANU : The display is scrolled when a disc is loaded
or when a track is changed, etc.
DEMO ON / DEMO OFF (Initial setting)
MP3/WMA/AAC
CD-DA (Initial setting) / CDDA/MP3
CD-DA : Only the CD data in Session 1 can be played
back.
CDDA/MP3 : CD data, MP3/WMA/AAC files in mixed mode,
and multi-session discs can be played back.
External Device
MUTE ON / MUTE OFF (Initial setting)
POW ON (Initial setting) / POW OFF
POW OFF : Use this mode when the line output of this unit
is used to drive an external amplifier. In this
setting, the head unit’s internal amplifier is
turned OFF and cannot drive speakers.
Amplifier
Front
left
Front
right
