27-EN
Specifications
FM TUNER SECTION
MW TUNER SECTION
LW TUNER SECTION
CD PLAYER SECTION
USB SECTION
GENERAL
CHASSIS SIZE
• Due to continuous product improvement, specifications and design
are subject to change without notice.
CAUTION
Tuning Range 87.5-108.0 MHz
Mono Usable Sensitivity 0.7 µV
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531-1,602 kHz
Sensitivity (IEC Standard) 25.1 µV/28 dB
Tuning Range 153-281 kHz
Sensitivity (IEC Standard) 31.6 µV/30 dB
Frequency Response 5-20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
USB requirements USB 1.1/2.0
Max. Power Consumption 500 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG-1/2 AUDIO Layer-3
WMA Decoding Windows Media™ Audio
AAC Decoding AAC-LC format “.m4a” file
Number of Channels 2-Channel (Stereo)
Frequency Response* 5-20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
* Frequency response may differ depending on the encoder
software/bit rate.
Power Requirement 14.4 V DC
(11-16 V allowable)
Maximum Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 60 Hz
Treble ±14 dB at 10 kHz
Weight 2.0 kg (4 lbs. 6 oz)
Width 178 mm (7")
Height 100 mm (3-15/16")
Depth 160 mm (6-1/4")
CLASS 1
LASER PRODUCT
(Bottom side of player)
