English
Adjusting the Z-Enhancer Plus
∗ This function cannot be adjusted when as
follows: “Pro Logic” is set to “ON”, the speaker
system is set to “5.1ch”, DVD/DTS-CD is being
played.
1. Press the [Z+] button and select the Z-
Enhancer Plus mode to adjust.
2. Press the [A-M] button and turn the
[ROTARY] knob to adjust the setting.
●When “B-BOOST 0” selected, you can
adjust the bass in the range of -3 to 3.
●When “IMPACT 0” selected, you can adjust
the bass and treble in the range of -3 to 3.
●When “EXCITE 0” selected, you can adjust
the bass and treble in the range of -3 to 3.
∗ When Z-Enhancer Plus is selected, press
and hold the [Z+] button for 1 second or
longer to change to the “CUSTOM” mode.
Bass/treble characteristics become flat and
the indication “Z+ FLAT” is shown in the
display.
Adjusting the tone
∗ This function cannot be adjusted when as
follows: “Pro Logic” is set to “ON”, the speaker
system is set to “5.1ch”, DVD/DTS-CD is being
played.
Press the [A-M] button and select the item to
adjust. Each time you press the [A-M] button, the
item changes as following order:
●When “BASS BOOST” is set
“CTR-VOL 0” ➜ “SW-VOL 0” ➜ “B-BOOST
0” ➜ “BAL 0” ➜ “FAD 0” ➜ Last function
mode.
●When “IMPACT” is set
“CTR-VOL 0” ➜ “SW-VOL 0” ➜ “IMPACT 0”
➜ “BAL 0” ➜ “FAD 0” ➜ Last function
mode.
●When “EXCITE” is set
“CTR-VOL 0” ➜ “SW-VOL 0” ➜ “EXCITE 0”
➜ “BAL 0” ➜ “FAD 0” ➜ Last function
mode.
●When “CUSTOM” is set
“CTR-VOL 0” ➜ “SW-VOL 0” ➜ “BASS” ➜
“TREBLE” ➜ “BAL 0” ➜ “FAD 0” ➜ Last
function mode.
●When “Z+ OFF” is set
“CTR-VOL 0” ➜ “SW-VOL 0” ➜ “BAL 0” ➜
“FAD 0” ➜ Last function mode.
∗ “CTR-VOL” does not appear when the speaker
system is set to “2ch”.
∗ The display automatically returns to the
previous mode when no operation is
performed.
Basic Operations
Adjusting the center speaker
∗ This function cannot be adjusted when as
follows: “Pro Logic” is set to “ON”, the speaker
system is set to “5.1ch”, DVD/DTS-CD is being
played.
∗ This function cannot be adjusted when the
center speaker output is set to “OFF” or the
speaker system is set to “2ch”. For details on
how to set the center speaker, refer to the
subsection “Turning on/off speakers” in the
section “Changing Initial Settings such as
Menu Language, etc.”.
∗ The factory default setting is “CTR-VOL 0”.
1. Press the [A-M] button and select “CTR-VOL
0”.
2. Turn the [ROTARY] knob to select from -4 to
+8 or OFF.
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the subwoofer
∗ This function cannot be adjusted when as
follows: “Pro Logic” is set to “ON”, the speaker
system is set to “5.1ch”, DVD/DTS-CD is being
played.
∗ This function cannot be adjusted when the
subwoofer output is set to “OFF”. For details on
how to set the subwoofer, refer to the
subsection “Turning on/off speakers” in the
section “Changing Initial Settings such as
Menu Language, etc.”.
∗ The factory default setting is “SW-VOL 0”.
1.
Press the [A-M] button and select “SW-VOL 0”.
2. Turn the [ROTARY] knob to select from -6 to
+6 or OFF.
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the bass
(Gain, Frequency, Q-curve)
∗ This function cannot be adjusted when as
follows: “Pro Logic” is set to “ON”, the speaker
system is set to “5.1ch”, DVD/DTS-CD is being
played.
∗ This adjustment can only be performed when
the Z-Enhancer Plus is set to “CUSTOM”.
1. Press the [A-M] button and select “BASS”.
2. Turn the [ROTARY] knob to adjust the bass.
∗ The factory default setting is “B
ÅÅ
ÅÅ
ÅGAIN
0Γ. (Adjustment range: -6 to +6)
+VXZ756_01-13-Eng.p65 05.3.1, 6:10 PM14
