IB-PDV722-WM-E-012007
1.The POWER switch is at the OFF position, please slide it to ON.
2.The built-in battery is depleted, please recharge the battery
or use the AC adaptor or car adaptor, make sure the AC
outlet has power.
3.The fuse in the car adaptor is blown. To change the fuse,
unscrew the tip, replace only with same 3A 250V fuse.
4. When you are using the main unit and the slave unit together,
make sure the two units are connected as the steps on pages
9, 10 and 12.
Remedy
TROUBLE SHOOTING
Symptom
No power.
1.Make sure all power cables are connected properly.
2.The disc may be damaged or scratched.
3.This player cannot play a DVD disc other than region 1 standard.
4.The disc may be dirty and may require cleaning.
5.Ensure that the disc is installed with the label side up (facing you).
6.If your disc is rented, it may be scratched or damaged from a
previous renter. Return it or polish it.
7.Condensation may have formed on your disc. Wait about 1
hour to allow the player to dry out.
1.Ensure that the equipment is connected properly. Double
check all cables and AC power.
2.Select the proper video channel on your TV set, VIDEO 1, 2, 3, etc.
3.Check if the proper AV input is selected on your TV set video
inputs (some TV sets have 3 or 4 different inputs).
4.Make sure both the TV and DVD player are on.
• Play fails to start even
when PLAY is pressed.
• Play starts but then
stops immediately.
No picture on your
external TV’s screen.
1.Picture is distorted during rapid advance or rapid reverse. The
picture may be somewhat distorted occasionally, this is normal.
General
2.Did you connect your DVD player to your VCR? Please
connect the player directly to your TV and disconnect the VCR.
This player has Macrovision copy protection, this will distort
pictures when used with VCRs.
The picture is distorted.
Battery drains too fast
in stop mode.
The set continues to be on even in stop mode. If you plan on
leaving the disc stopped for a longer time, turn the set’s power
off to conserve battery power or use the AC adaptor.
Some lines appear on
the screen during the
startup of the vehicle.
Please turn the unit off and turn it on again after the vehicle is
running.
No image on the main
unit’s LCD screen.
The main unit’s LCD may be turned off.
1.Make sure the main unit’s DISPLAY ON/OFF switch is at the ON
position.
2.Press and hold the SCREEN ON/OFF button on the remote or
turn the player off and turn it on again.
No image on the slave
unit’s LCD screen.
1.Make sure the two units are connected correctly.
2.Make sure the POWER switch is at the ON position of both sets.
28
Slave unit cannot be
adjusted.
Only the main unit can be adjusted, the slave unit is just a
second screen with speakers.
IB-PDV722-WM-E-012007.pmd 2/12/2007, 1:20 AM29
