11
OPERATION – BASIC
• P. PLAY [EJ MUTE] — Plays the Tuner after you eject a CD while Eject Mute mutes the Tuner
after you eject a CD.
• V/BAR ON [V/BAR OFF] — Displays the Volume Bar at the bottom of the Front Panel while
Volume Bar Off turns it off.
• INI VOL 15 — Sets the maximum Initial Volume when the unit turns on. Initial Volume sets
point of maximum volume when the unit is turned on. If the volume setting was lower than the
initial volume setting when the unit is turned off, then the lower volume will be used at turn on.
If the volume setting was higher than the initial volume setting, then the initial volume setting is
used at turn on. This feature prevents accidental high volume turn on as well as allows high
volume settings to be retained in case another preamplifier is the system’s main volume control.
• CONTRAST [VIEW 6] — Controls the view angle of the display. Allows adgustment for best
visibility.
• SUM FLAT [80HZ] (Model 9210 only) — Means third pair of RCA pre-outs is full-range while
80Hz means that the pre-outs are crossed-over 80Hz low-pass for subwoofer use.
• PANEL AUTO [PANEL MANU] — Automatically opens and closes Panel when loading or
ejecting discs while PANEL MANU allows the front panel to remain open and CDs to be
manually loaded or ejected. Allows use of radio with the panel down.
• SCROLL ON [SCROLL OFF] — Titles scroll across panel screen. Scroll Off prevents scrolling..
• AUX1 IN 0 [+6, –6] — Allows you to boost the input volume of a weak external audio source
or diminish a powerful one. Useful for external sources: MP3 players, video games, VCPs, etc.
CLOCK OPERATION
Setting the Clock Hours
1. Press and hold the DISP button for 1 second until the hour flashes.
2. Press UP or DOWN button (SEEK or ) to set the hour.
Setting the Clock Minutes
1. Press and the DISP button a second time and the minutes will flash.
2. Press UP or DOWN button (SEEK or ) to set the minutes.
Your settings will be saved after the clock has flashed for 5 seconds.
NOTE: When the radio is off (sleep mode) the clock will be displayed.
MODE SELECTION
Press the MODE button repeatedly to cycle through the following modes:
• CDP PLAY — Enables CD Player if a CD is inserted.
• AUX1* — Allows for an external audio source to attach to the sound system.
• TUNER — Enables the Tuner.
MUTE
1. Press the MUTE button to dampen the volume.
2. Press the MUTE button a second time to revert the
audio to the previous level.
NOTE: The panel will display MUTE until the function
is canceled.
Remote
Remote
