19-EN
CD Player/Changer Operation (Optional)
2 Press the Disc Select buttons (1 through 6)
corresponding to one of the discs loaded in the
CD Changer. The selected disc number appears
in the display and CD playback starts.
NOTES
• After selecting the desired disc, you can operate in the
same way as for the CVA-1003 CD player.
For details, please see the CD Operation section.
• When the “FUNC” indicator is lit in red in the
monitor display, or is lit in the sub display, the disc
select buttons become nonfunctional.
When a 12-disc CD Changer is connected:
To select discs numbered from 1 to 6, the
procedure is the same as for the 6-disc CD
Changer. To select discs numbered from 7 to 12,
first press the FUNC button. In the sub display,
this changes the "D" indicator to "d." The "FUNC"
indicator is lit in yellow on the monitor display.
Then press the desired Preset button. With the
FUNC button activated, the Preset buttons 1 to 6
will represent discs 7 to 12 respectively.
Multi-Changer Selection
Alpine's Ai-NET system will support up to 6 CD
Changers. When operating two or more changers,
the KCA-400C (Multi-Changer Switching device)
must be used. If you use 1 Switching device, you
can connect up to 4 CD Changers. If you use 2
Switching devices, you can connect up to 6 CD
Changers.
1 Press the SOURCE button on the CVA-1003 to
activate the CD Changer mode.
Alternatively, press the SOURCE button on the
Remote Control (optional) to activate the CD
Changer mode. Proceed to step 3 below to
select the desired CD Changer.
2 Press the BAND button on the CVA-1003 or the
Remote Control to activate the CD Changer
Selection mode.
3 The CD Changer Selection mode remains active
for 3 seconds after step 2 is performed. Press
the BAND button until the desired CD Changer
indicator appears on the display.
NOTE
If the selected CD Changer is not connected, the display
will show "NO CHANGER."
Alternatively press the BAND button on the
Remote Control until the desired changer
indicator appears on the display.
4 To operate the selected changer, see "CD Player
Operation" section.
NOTE
If an optional CD/MD/DVD player is connected to the
unit, the disc mode can be switched each time you press
the BAND button (see "Switching Disc Mode" on page
39.)
