Other Useful Features
Setting the Bass Control
You can change the Bass Frequency emphasis to
create your own tonal preference.
1 When the monitor display is open, press the bass
engine button. Bass engine mode is displayed in
the monitor display.
2 Press the Preset 1 button to select the desired
mode.
3 Press the g DN or f UP button to adjust
the selected mode.
• Bass Level : -7~+7
You can emphasize or weaken the bass
frequency.
• Bass center frequency :
60Hz ↔ 70Hz ↔ 80Hz ↔ 90Hz ↔ 100Hz ↔ 130Hz ↔ 150Hz ↔ 200Hz
Emphasizes the displayed Bass frequency
ranges.
• Bass Band Width (Q-Factor):
WIDE1 ↔ WIDE2 ↔ WIDE3 ↔ WIDE4
(Narrow)
←
..............................
→
(Wide)
Changes the displayed frequency's band width
to wide or narrow.
4 Press the bass engine button to return to the
normal mode.
NOTES
• If no buttons are pressed within 10 seconds, the Bass
control setting will be turned off automatically.
• Depending on the type of external audio processors
connected to the unit, you may not be able to set some
settings.
• The settings of the Bass will be individually
memorized for each source (FM, AM and CD) until
the setting is changed. Depending on the connected
devices, some functions and display indications do not
work.
Operation with the monitor display closed
You can set the Bass control with the monitor
display closed.
1 Press the bass engine button.
2 Press the Preset 1 button. BASS is displayed
for 2 seconds in the sub display, then the
value of BASS Level blinks.
3 Each time you press the Preset 1 button, the
blinking shifts.
Example of sub display
4 Press the g DN or f UP button to
adjust the selected mode.
gg
gg
g DN
ff
ff
f UP
Preset 1
Preset 2
gg
gg
g DN
ff
ff
f UP
Preset 1
Preset 2
bass engine
bass engine
