36-EN
Selecting Rear Monitor
When using the optional expansion BOX (KCE-
103V), If AUX/NAV. is to ON in "Setting the
External Input (page 37), and if a rear-seat
monitor and navigation system are connected to
the CVA-1003, you can switch the picture/sound
of the rear-seat monitor from the CVA-1003.
After carrying out the steps 1 to 3 of "To display
the SETUP screen" described on page 31,
perform the operation show below.
1 When the monitor display is open, press and
hold the SETUP button for at least 2 seconds.
The SETUP screen appears.
2 Press the Preset 3 button to activate the
AUXILIARY setting mode. Press the Preset 3
button again to select AUX OUT.
3 Press the g DN or f UP button to activate
the AUX OUT setting mode.
AUX-1 IN : the picture/sound of the device
connected to Terminal AUX 1 will be
played on the rear-seat monitor.
AUX-2 IN : the picture/sound of the device
connected to Terminal AUX 2 will be
played on the rear-seat monitor.
NAV.IN : the navigation screen will be
displayed and the voice guidance will
be produced on the rear-seat monitor
if the navigation system is
connected.
OFF : mode cancel AUX OUT.
To set another setting, press the Preset 3 button
or another Preset button.
Other Useful Features
4 After setting is completed, Press the SETUP
button to return to normal mode.
NOTE
If a DVD player or DVD changer is connected to the
AUX 1 or AUX 2 terminal, the DVD picture appears by
performing steps 1 and 2 of "Simultaneous Operations"
on page 39. Then, perform steps 1 to 4 on this page so
the DVD picture and sound are output.
gg
gg
g DN
ff
ff
f UP
Preset 3
SETUP
Preset 5
