38-EN
Other Useful Features
Subwoofer Control On and Off
After carrying out the steps 1 to 3 of "To display the
SETUP screen" described on page 31, perform the
operation show below.
1 When the monitor display is open, press and
hold the SETUP button for at least 2 seconds.
2 Press the Preset 6 button to set to the SYSTEM
setting mode. Press the Preset 6 button again to
select the SUB W. mode.
3 Press the g DN or f UP button to select
Subwoofer ON or OFF.
To set another setting, press the Preset 6 button
or another Preset button.
4 After setting is completed, press the SETUP
button to return to normal mode.
NOTES
• Initial mode is "Subwoofer ON."
• Set to "Subwoofer OFF" unless the subwoofer is used.
• When the subwoofer is turned on, the subwoofer
output level can be adjusted. For more details, refer to
the Adjusting Volume/Balance/Fader.
Interrupt Feature (MIX LEVEL)
With an Alpine navigation system connected to
the CVA-1003, the voice guidance of the
navigation system will be mixed with the radio or
CD/MD audio. You can also adjust the volume
level of the voice guidance.
If you use this unit connected to an external audio
processor, use the built in amplifier. You cannot
use this function with an external amplifier.
After carrying out the steps 1 to 3 of "To display
the SETUP screen" described on page 31,
perform the operation show below.
1 When the monitor display is open, press and
hold the SETUP button for at least 2 seconds.
The SETUP screen appears.
2 Press the Preset 6 button to activate the
SYSTEM setting mode. Press the Preset 6
button again to select MIX LEVEL.
3 Press the g DN or f UP button to adjust
the volume level of the navigation system's voice
guidance in 7 steps.
To turn off the navigation system's voice
guidance, press this button repeatedly until OFF
appears.
To set another setting, press the Preset 6 button
or another Preset button.
4 After setting is completed, Press the SETUP
button to return to normal mode.
NOTES
• The volume level of the audio will be automatically
reduced when the voice guidance of the Navigation
system starts.
• When the voice guidance of the Navigation system
starts to interrupt the audio, the display is
automatically changed to the navigation screen.
gg
gg
g DN
ff
ff
f UP
SETUP
Preset 6
V.SEL
BAND
