Connecting Your TV
Connect the DVD receiver to the TV directly. If you con-
nect the DVD receiver to a VCR, TV/VCR combination,
or video selector, the playback picture may be distorted
as DVD videos are copy protected.
Using Video
Connect the VIDEO OUT to a set of VIDEO input on
your TV.
Use the supplied video cable (RCA), connecting the
yellow plug to the video output.
See the following page if you want to use a compo-
nent or S Video cable for the video connection.
Using S Video
If your TV (or other equipment) has an S Video input,
you can use this instead of the standard (composite) out-
put for a better quality picture.
• Use an S Video cable (supplied) to connect the S
VIDEO OUTPUT to an S Video input on your TV (or
monitor or AV receiver).
Line up the small triangle above the jack with the same
mark on the plug before plugging in.
Using Component Video
You can use the component video output instead of the
standard video out jack to connect this player to your TV
(or other equipment).
This should give you the best quality picture from the
three types of video output available.
• Use a component video cable (not supplied) to con-
nect the COMPONENT VIDEO OUTPUT jacks to a
component video input on your TV, monitor or AV
receiver.
Note:
Watching progressive scan video from the component
video outputs.
This player can output progressive scan video from the
component video output. Compared to interlace video,
progressive scan video effectively doubles the scanning
rate of the picture, resulting in a very stable, flicker-free
image. To set up the player for use with a progressive
scan TV, see Video Output settings on page 70. When the
player is set to output progressive scan video, the
PRGSV indicator lights in the front panel display.
Important:
If you connect a TV that is not compatible with a pro-
gressive scan signal and switch the player to progressive,
you will not be able to see any picture at all. In this case,
return the setting from “Progressive” to “Interlace” by
following the way described in Note on page 70.
TV
Video cable
(Supplied)
TV
S-Video cable
(Not supplied)
YPB PR
COMPONENT
VIDEO IN
TV
