116
Audio Processor
Operation (Optional)
Selecting DHE (Digital
Harmonic Enhancer)
Mode
The DHE mode enhances the sound of musical
instruments or vocals, while masking road
noises of a moving vehicle. The result is music
with more clarity.
Press the SOURCE button.
The main menu screen appears on the display.
1
Press the 4 (A.PROC) button to display the
Audio Processor List screen.
2
3
Rotate the rotary encoder and select "DHE,"
then press the rotary encoder to execute the
selection.
The DHE mode screen appears.
Press one of the Function buttons 2 (MODE1)
through 6 (MODE5) that has your desired
DHE mode. There are 5 modes as follows.
When the 1 (OFF) button is pressed, the DHE
mode will be deactivated.
4
Beat MIX
(MODE3)
Balances the bass sound
to make it brighter.
Beat MAX
(MODE1)
Lyric MIX
(MODE4)
Reproduces voice of
female singers clearer.
Lyric MAX
(MODE2)
Phase MIX
(MODE5)
Reproduces any kind of
music sources more
balanced and crisp.
Enhances voice of female
singers to make it brighter.
Enhances the rhythmic bass sound
to make very harmonic bass sound.
(To be continued)
3
1
24 5
A.PROC
MODE 1 MODE 2 MODE 3 MODE 4 MODE 5
