142
Audio Processor
Operation (Optional)
Press and hold the FUNC (RETURN) button for
at least 2 seconds in the Divider mode.
The mode changes to the Divider Adjustment
mode.
1
Press the 3 (T-CORR.) button.
The mode changes to the Time Correction
Adjustment mode.
2
3
Adjusting Time -
Correction for 2-Way
Speaker System
Use this procedure to adjust the sound time
difference between the speakers.
(To be continued)
Press the rotary encoder and select the channel
you wish to adjust.
Each press changes the channels as follows:
When only one 2-way divider is connected:
→ L-Low → R-Low → F-High/L
R-High/R ← R-High/L ← F-High/R ←
When two 2-way dividers are connected:
→ L-Low → R-Low → L-High → R-High
Each time the 6 (F/R) button is pressed,
the mode switches between the Front
adjustment and Rear adjustment modes,
and the display also changes.
→ L-Low → R-Low → L-High → R-High
When only one 3-way divider is connected:
→
L-Low
→
R-Low
→
L-Mid
→
R-Mid
→
L-High
→
R-High
When two 3-way dividers are connected:
→
L-Low
→
R-Low
→
L-Mid
→
R-Mid
→
L-High
→
R-High
Each time the 6 (F/R) button is pressed,
the mode switches between the Front
adjustment and Rear adjustment modes,
and the display also changes.
→
L-Low
→
R-Low
→
L-Mid
→
R-Mid
→
L-High
→
R-High
↓
↓
2
15
34
RETURN
T-CORR
↑
↑
