English
138
Audio Processor
Operation (Optional)
↓
(To be continued)
Press and hold the FUNC (RETURN) button for
at least 2 seconds in the Divider mode.
The mode changes to the Divider Adjustment
mode.
1
Press the 2 (LEVEL) button. The mode
changes to the Level Adjustment mode.
2
Adjusting Levels
3
↓
Press the rotary encoder and select the channel
you wish to adjust.
Each press changes the channels as follows:
When only one 2-way system divider is
connected:
→ L-Low → R-Low → F-High/L
R-High/R ← R-High/L ← F-High/R ←
When two 2-way system dividers are connected:
→ L-Low → R-Low → L-High → R-High
Each time the 6 (F/R) button is pressed,
the mode switches between the Front
adjustment, and Rear adjustment modes,
and the display also changes.
→ L-Low → R-Low → L-High → R-High
When only one 3-way divider is connected:
→ L-Low → R-Low → L-Mid → R-Mid → L-High → R-High
When two 3-way dividers are connected:
→ L-Low → R-Low → L-Mid → R-Mid → L-High → R-High
Each time the 6 (F/R) button is pressed,
the mode switches between the Front
adjustment and Rear adjustment modes,
and the display also changes.
→ L-Low → R-Low → L-Mid → R-Mid → L-High → R-High
2
15
34
RETURN
LEVEL
↑
↑
