English
224
Remote Control
(RUE-4165 supplied with IVA-C800)
Basic Mode
1Remote Control Signal Transmitter
2Signal Transmitter Indicator
3Rotary Encoder/Volume Control
Rotate to the right or left in the same manner
as for the Rotary Encoder on IVA-C800.
4NAVI/AUDIO Switch
NAVI: Select this position to activate
Navigation mode.
AUDIO: Select this position to activate Audio
mode.
5ENTER Button
•Press to execute the selection. (The same
function as the rotary encoder on IVA-C800.)
•Pressing and holding this button for more
than 2 seconds turns the loudness on or off
(when neither an equalizer nor a digital
sound processor is connected).
:/J Button
Press and hold this button for more than 2
seconds to play or pause.
6A.PROC (Audio Processor) Button
Switches the audio processor modes such
as equalizer, surround, etc.
7MUTE Button
Press the button to lower the volume level by
20 dB instantly. Press the button again to
return to the previous volume level.
8TUNER Button
Press the button to select the radio mode.
9DISC Button
Press to switch to the CD (built-in CD player)
mode.
!CHG (Changer) Button
Press to switch to the changer mode.
"POWER Button
Press to turn the power On or Off.
#Numeral Keys
The key numbers from 1 to 7 have the same
functions as for the 1 to FUNC buttons on
IVA-C800.
$DEL (Angle Down) button
Pressing this button changes the monitor
angle downward.
%"O" (Open/Close) Button
• When the monitor is closed: raises the
monitor.
• When the monitor is open: houses the
monitor into the monitor compartment.
• When the monitor is open: Each time you
press and hold the "O" (Open/Close) button
for more than 2 seconds, the monitor Slides
back and forth.
&"OK" (Angle Up) Button
Changes the monitor angle upward.
* Not used.
DEL
OK
12
3
45
6
78
9
0
SOURCE
MENU
BAND
CANC.
POWER
V.SEL
DETOUR
DISC
PLAN
CHG
DEFEAT
MUTE
DISP
LIST
V
O
L
D
N
V
O
L
U
P
A.PROC
VOICE MP/RG
LIST
TUNER
DISP
ON/OFF
DEL DEST.
ENT
N/H
5
8
2
4
!
3
7
9
6
1
"
$
&
∗
#
%
