NZ503 Functions of Buttons
Note: Be sure to read this chapter while referring to front
diagram “PANEL CONTROLS”.
[NAVI/AV]Button
• Pressthisbuttontoenternavigationmode;press
again to return current source.
• Pressandholdthisbuttonfor3secondstodisplay
the brightness setting panel.
• Press this key to change display of sub LCD when
panel is closed.
[ ]EjectButton
• Presstoejectdiscfromunit.
[MIC]
• InternalmicrophoneforuseduringBluetoothphone
calls.SensitivitycanbeadjustedfromtheSettings
menu.
[RESET]Button
• Pressthisbuttontohardwareresettheunit.
Note: When the [RESET] button is pressed, frequencies
of radio stations, titles, etc. stored in memory are
cleared.
[AUX 1 JACK]
AUX1Connector.
[ , ]Buttons
• Shortpresstosearchnexttrackorchapterin
Pandoramode.
• ShortpresstopresetuporpresetdowninTuner,
SiriusXMmodes.
• PressandholdtoseekuporseekdowninTuner
mode.
• Pressandholdtochanneluporchanneldownin
SiriusXMmode.
• Shortpresstosearchpreviousornexttrackor
chapterinCD/DVD,USB,iPodandBTaudio
modes.
• Pressandholdtoprogressivefastforwardand
progressivefastreverseinCD/DVD,USB,modes
• Pressandholdtofastforwardorfastbackwardin
iPodmode.
[OPEN]
[ISR/SEND]
[ / ]
[VOL-]
[VOL+]
[IR]
[ ]
[ ]
[ ]
[BND/END PS]
[NAVI/AV]
[MIC]
[RESET]
[AUX 1 JACK]
[MENU/POWER]
[microSD]
4. PANEL CONTROLS
