Preset Scan
ThePresetScanreceivesthestationsstoredinthe
preset memory in order. This function is useful when
searching for the desired station in memory.
1. Touch the [FM1/2/3/AM] key to select the desired
band.(FMorAM)
2. Touch the [ ]keytostartthePresetScan.
The unit starts scanning each station for 10 seconds
sequentially.Butthestationstoredisnotavalid
station;thescanningtimeisonly2seconds.
3. When the desired station is tuned in, touch the
[ ] key again to stay in that station.
LOC/DX Setting
TheDX/LOCsettingchangesthetunersensitivityin
order to separate closely spaced stations. This feature
is useful in areas that have many radio stations in
close proximity.
1. Touch the [ ]keytoswitchtoLOCALtuner
sensitivity.
2. Touch the [ ]keytoswitchtoDXtuner
sensitivity.
17. HD Radio™ RECEIVER OPERATIONS
ThisfunctionisavailablewhenanHDRadiotuneris
connected.
ThisunitcancontrolthefollowingHDRadiotuner:
•HDRadioTuner(THD400)
Note:
• Be sure to turn off the ACC power before connecting/
disconnecting the HD Radio tuner.
• Not all areas offer HD Radio broadcasts
• HD Radio stations may not always broadcast sub
channels
• Volume levels of HD Radio stations may vary. Increase
the volume gradually from the minimal setting after
the channel is selected. Be sure to lower the volume
setting before switching to another mode or channel.
AdditionalinformationaboutHDRadiocanbefound
at www.hdradio.com
Listening to HD Radio
Note: Connect THD400 HD Radio
TM
black box to
activate HD Radio function.
1.TouchtheTunerbuttonontheMainmenudisplay.
TheHDRadiomodescreenwillbedisplayed.
2.Pressthe[FM1/2/3/AM]buttonortouchthe[Band]
key on remote control to select the radio band. Each
time the button is pressed, the radio reception band
changesinthefollowingorder:FM1,FM2,FM3,AM,
FM1...
8 67
2 3
9
5
4
1
1.BandDisplay
2.BluetoothStatusDisplay
3. Time Display
4.TuneUp
5. Tune Down
6.PresetListButton
7.DirectButton
8.resetScanButton
9.SettingButton
Seek Tuning
1.Pressthe[FM1/2/3/AM]buttontoselecttheradio
band(FMorAM).
2. Touch the [ ]key,andthenicktheBIG
Frequencyupanddowntosearchfornextavailable
station.
•Whenickthefrequencyup,thestationissearched
inthedirectionofhigherfrequency.•Whenick
thefrequencydown,thestationissearchedinthe
directionoflowerfrequency.
