21. REAR SOURCE OPERATIONS
If rear monitors are installed in the rear seat and
connectedtotherearzoneAVoutput,passengersin
thebackseatscanwatchtheDVD/iPodVideo/AUX1/
AUX2videoseparatelyfromfrontsource.
1 2
1.Pressthebuttontoaccesstherearsourcemenu.
2.Pressthebuttonagaintobacktofrontsource
menu.
Multi-Zone Operation
Independent sources can be played simultaneously
ontheunit.Forexample,aFM/AMconsolecanbe
playback on the front screen while DVD video is
availabletorearpassengers.Butnowcan’tselectDVD
video in front.
AccessRear-Zone
1. Touch the Rear button [ ]onMainMenuto
accesstheRearSource.
2.UsetheMulti-ZoneRemoteControltoaccessthe
Rear-Zoneandselectasourcetoplay.
ExitRear-Zone
1.Touchthe2-Zoneoff[ ]buttontoclosetheRear
Source.
2.UsetheMulti-ZoneRemoteControltoclosed
NOTE:
1.If the source is selected as the front, the source in rear
can’t be selected.
2.If the source is selected as the rear, the source in front
can’t be selected.
3.Press the Front Button to access the main
menu but not close the Rear
DVD Video in Rear
1 2
7
3 4 5 6
1. [ ]:NextRowButtons
Pressthebuttoncandisplaythehiddenbutton.
2. [ ]:Previouschapter.
3. [ ]:PlayorPausevideo.
4. [ ]: Next chapter.
5. Elapsed playing time indicator.
6. [ ]MenuButton
7. [ ]/[ ]: Front/Rear switching button
IfthescreendisplaysRearSource,press[ ] to
switchtoFrontSource.
IfthescreendisplaysFrontSource,Press[ ] to
switchtoRearSource.
8 9
7
10 11 12
8. [ ]:AudioChannelswitchingButton.
UsetorepeattheTitleorChapter.
PressoncetostartRepeatChapter.Pressagainto
activate Repeat Title. To turn Repeat off, press same
button again. Repeat symbols are displayed in the
info window in the upper left area of the screen.
9. [ ]:AudioChannelswitchingButton
10. [ ]:SubtitleswitchingButton
11. [ ]:INFOButton
12. [ ]:DirectchapterortitlesearchingButton
