12 NZ503
English
English
Owner’s Manual
English
Owner’s Manual
[ / ]Button
• Pressthisbuttontoplayorpausevideoandaudio
media.
• Pressthisbuttonmorethan1secondtostopvideo
and audio media.
•PresstoMUTEinTunermode.
[MUTE]Button
• MuteorUnmutethespeaker.
• Thesymbol on upper right area of the screen
indicates that speaker is muted.
[POWER/SRC]Button
• Pressthisbuttontomovethefocustonextavailable
source item on main menu.
• Pressthisbuttontopoweronwhentheunitis
power off.
• Pressthisbuttonmorethan1secondtopoweroff
when the unit is power on.
Note: While panel is closed position, you cannot select
any souce.
[0 - 9]Buttons
• UseintheKeyPadscreentoselecttheradioor
DVB-Tchannels.
• Usetoselectthetrackinthetracklistscreen.
• PresstoenterDVDvideochapters/titlesintheKey
Padscreen.
[VOLUME]Buttons
• Increaseanddecreasevolume.
[NAVI/AV]Button
• Pressthisbuttontoswitchbetweencurrentsource
and current position on navigation map.
[SRCH]Button
• Pressthisbuttontoopenchapterortitlesearch
window while playing DVD.
[BAND]Button
• Switchtonextbandalternately.
[SET]Button
• PressthisbuttontoopentheAudiosettingmenuin
any mode.
[BACK]Button
• Pressthisbuttontoquitmainmenuifcurrentscreen
is main menu.
[ ], [ ], [ ], [ ]Buttons
• Pressthisbuttonforcursormovementinmainmenu
orSettingmode.
• Fromthemainmenu,youcanselectyourdesired
source or change your settings.
•PressthisbuttonforcursormovementinDVDMenu.
[MENU]Button
• PressthisbuttontoentertheMAINMENUorreturn
current resource.
[PIC]Button
•Pressandholdthisbuttontochangeyourmonitor
brightness.
[ENT]Button
• PresstoxtheentereddataintheKeyPadscreen
or enter the item the cursor is on.
[TAG]Button
• PressthisbuttontorecordTAGinHDRadiomode.
[TITLE]Button
• PresstogotothetitlemenuontheDVD.
[ROOT]Button
• PresstogototherootmenuontheDVD.
[RPT]Button
• Presstoperformchapterrepeat/titlerepeat/
repeat off while playing DVD mode.
• Presstoperformtrackrepeat/repeatoffwhile
playing CD.
• Presstoperformrepeattrack/repeatfolder/repeat
offwhileplayingMP3/WMA,orvideolesondisc.
• Presstoperformrepeattrack/repeatfolder/repeat
offwhileplayingMP3/WMA,orvideolesinUSB
memory.
• Presstoperformrepeatone/repeatall/repeatoffin
iPodmode.
[ ] Buttons
•Short press to preset down in Tuner,SiriusXM
modes.
Press and hold to seek down in Tuner mode.
Press and hold to channel up in SiriusXM mode.
• ShortpresstosearchtrackorchapterupinCD/DVD
video,USBiPodandBTaudiomodes.
• Pressand hold to progressive fast reverse in CD/
DVD,USBmodes.
• PressandholdtofastbackwardiniPodmode.
[ ] Buttons
• ShortpresstopresetdowninTuner,SiriusXM
modes.
Pressand hold to seek down in Tuner mode.
Pressand hold tochannelupinSiriusXMmode.
• ShortpresstosearchtrackorchapterdowninCD/
DVD,USB,iPodandBTaudiomodes.
• Pressand hold to progressive fast forward in CD/
DVD,USBmodes.
• PressandholdtofastforwardiniPodmode.
Functions of Remote Control Buttons
You can use the remote control unit to control the NZ503.
Note:
•Thewirelessremotecontroloperationmaynotbeoptimalindirectsunlight.
