16 VRX6671z
8. OPERATIONS
Basic Operations
Note: Be sure to read this chapter referring to the front diagrams of
chapter 2. CONTROLS on page 5 (unfold).
CAUTION
When the unit is turned on, starting and stop-
ping the engine with its volume raised to the
maximum level may harm your hearings. Be
careful about adjusting the volume.
Note:
Use this unit after starting the engine.
Turning on and off the power
Note:
Be careful about using this unit for a long time with-
out running the engine. If you drain the cars bat-
tery too far, you may not be able to start the en-
gine and this can reduce the service life of the
battery.
1. Press the POWER button 1.
2. The illumination and display on the unit light
up. The unit automatically remembers its last
operation mode and will automatically switch
to display that mode.
3.
Press and hold the POWER button 1 for 1 sec-
ond or longer to turn off the power for the unit.
Note:
About the SYSTEM CHECK
The confirmation of connected equipment must be
performed for this unit only when the wiring con-
nection is complete and power is turned on to the
unit first. When the power is supplied, SYSTEM
and PUSH PWR appear alternately in the dis-
play. Press the POWER button
1
, the system
check starts inside the unit. When COMPLETE
appears, press once again the POWER button
1
.
Selecting a mode
1. Press the FUNC button 1 to change the mode
of operation.
2. Each time you press the FUNC button 1, the
mode of operation changes in the following
order:
Radio mode CD changer mode MD
changer mode TV mode Radio mode...
External equipment not connected with CeNET
is not selected.
Adjusting the volume
Operate the VOLUME button 2 in the direction
of the arrows
ww
ww
w (up) or
zz
zz
z (down) to adjust the
volume;
ww
ww
w: Increases the volume.
zz
zz
z: Decreases the volume.
The volume level indicated in the display is in a
range from 0 (minimum) to 33 (maximum).
CAUTION
While driving, keep the volume at a level at
which external sounds can be heard.
Switching the display
When the panel is closed:
Press the DISP button
@
to select the desired dis-
play.
Each time you press the DISP button @, the dis-
play switches in the following order:
Notes:
Once selected, the preferred display becomes the
default display. When a function adjustment such
as volume is made, the display momentarily
switches to that functions display, then returns
back to the preferred display several seconds af-
ter the adjustment.
