Alpine PXA-H700 Car Stereo System User Manual



18-EN
MX settings
MX (Media Xpander) makes vocals or
instruments sound distinct regardless of the
music source. The radio, CD, and MP3, will be
able to reproduce the music clearly even in cars
with a lot of road noise.
1
When “Auto” has been set as the MX mode
setting (see page 27) while using the PXA-
H700 in combination with an Ai-NET head
unit equipped with an automatic MX mode
selection function (DVA-7996, etc.)
In this case, the MX mode is selected
automatically according to the music source on
the head unit. The MX mode can be set from
the PXA-H700 using the operation described
below.
1 Press the MX button to set the MX setting mode.
2 In case of “MX OFF”, press and hold the MX
button for at least 2 seconds to turn the MX
mode on.
3 Turn the Rotary encoder to select the desired
mode, then press the ENTER button.
When “OFF” is selected, the MX effect is
turned off.
The level for the currently selected music
source (radio, CD, etc.) can be adjusted.
FM: MX1 to 3 and OFF
The medium to high frequencies become
more clear, and produces well balanced
sound in all the bands.
CD: MX1 to 3 and OFF
CD mode processes a large quantity of data.
This data is used to reproduce the sound
cleanly by making use of the data quantity.
MP3/XM: MX1 to 3 and OFF
This corrects information that was omitted at
the time of compression. This reproduces a
well-balanced sound close to the original.
DVD/Video CD: MOVIE MX 1~2, MUSIC, OFF
MOVIE MX 1~2: The dialogues of movies
are played with greater clarity.
MUSIC: Discs containing music clips are
played with a more dynamic sound.
AUX: MP3, MUSIC, MOVIE, OFF
Choose the MX mode (MP3, MUSIC, or
MOVIE) that corresponds to the media
connected.
4 Once the settings are completed, press the MX
button.
NOTES
Operations cannot be performed when the defeat
mode (page 28) is on.
Each music source, such as radio, CD, and MP3 can
have its own MX setting.
If "MX OFF" is set in step 2, the MX mode is set to
off for all music sources.
2
When combining non Ai-Net head unit
products
When combining Ai-Net head unit products
without MX interlocking function
When combining Ai-Net head unit products
(DVA-7996, etc.) with MX interlocking
function considering that “MX mode setting”
(page 27) is set to “Manual”.
In these cases, the PXA-H700 is not interlocked
with the head unit, therefore it is necessary to set
the MX from the PXA-H700 with the operations
below.
1 Press the MX button to set the MX setting mode.
2 In case of “MX OFF”, press and hold the MX
button for at least 2 seconds to turn the MX
mode on.
Settings/Adjustments
ENTER
MX
B.C.
Rotary encoder
