Specifications
Graphic EQ number of bands:
Front (left and right) 31 bands
Rear (left and right) 31 bands
Center 31 bands
Subwoofer 10 bands
Graphic EQ boost cut
range: ±9 dB
Parametric EQ number of bands:
Front/rear/center 5 bands
Subwoofer 2 bands
Parametric EQ frequency:
Front, Rear and Center
Band 1: 20/22/25/28/31.5/36/40/45/50/56/
63/71/80/90/100/110/125/140/160/
180/200/220/250/280/315/360/400/
450/500 (Hz)
Band 2: 50/56/63/71/80/90/100/110/125/
140/160/180/200/220/250/280/315/
360/400/450/500/560/630/710/800/
900/1k/1.1k/1.2k (Hz)
Band 3: 125/140/160/180/200/220/250/280/
315/360/400/450/500/560/630/710/
800/900/1k/1.1k/1.2k/1.4k/1.6k/
1.8k/2k/2.2k/2.5k/2.8k/3.2k (Hz)
Band 4: 315/360/400/450/500/560/630/710/
800/900/1k/1.1k/1.2k/1.4k/1.6k/
1.8k/2k/2.2k/2.5k/2.8k/3.2k/3.6k/4k/
4.5k/5k/5.6k/6.3k/7.1k/8k (Hz)
Band 5: 800/900/1k/1.1k/1.2k/1.4k/1.6k/
1.8k/2k/2.2k/2.5k/2.8k/3.2k/3.6k/4k/
4.5k/5k/5.6k/6.3k/7.1k/8k/9k/10k/
11k/12.5k/14k/16k/18k/20k (Hz)
Subwoofer
Band 1: 20/22/25/28/31.5/36/40/45/50/56/
63/71/80 (Hz)
Band 2: 50/56/63/71/80/90/100/110/125/
140/160/180/200 (Hz)
Parametric EQ boost cut
range: ±9 dB
Time correction control
range: 0 to 20 ms (0.05 ms steps)
Frequency response: 20 Hz to 20 kHz
S/N ratio: 95 dB
Channel separation: 70 dB
Input sensitivity: 850 mA (2V for analog 1 only)
Subwoofer crossover: 20 to 200 Hz (1/6 oct. steps)
Rated output: 4V (with 10 k ohms load)
Input impedance: 10 k ohms or greater
Output impedance: 1 k ohm or less
Weight: Control unit 159 g (5 oz)
Base unit 1.1 kg (2 lbs. 6 oz)
Dimensions
Control unit
Width 170 mm (6-3/4")
Height 46 mm (1-13/16")
Depth 24 mm (15/16")
Base unit
Width 260 mm (10-3/16")
Height 40 mm (1-9/16")
Depth 160 mm (6-1/4")
<Components>
Parts name Quantity
Parts for mounting ................................ 1set
Owner’s manual.................................... 1set
Microphone........................................... 1set
Due to continuous product improvement,
specifications and design are subject to change
without notice.
The illustrations included in these instructions may
appear different from the actual product due to
printing conditions.
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are
trademarks of Dolby Laboratories. Confidential
unpublished works. ©1992-1997 Dolby Laboratories.
All rights reserved.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942 and other
worldwide patents issues and pending. “DTS” and
“DTS Digital Surround” are trademarks of Digital
Theater Systems, Inc. © 1996 Digital Theater
Systems, Inc. All rights reserved.
