4 Turn the Rotary encoder to select “Auto”, then
press the ENTER button. Test tone output is
repeated for each of the different speaker
channels. They will be repeated in the order
shown below.
If no operation is performed for 2 seconds, the
channel switches to the next channel.
5 While the test tones are being produced from the
speakers, turn the Rotary encoder to adjust so
that the volume of the different speakers is
equal.
• The adjustment range for the different
speakers is ± 10 dB.
• Adjust based on the front speakers.
6 Press the SETUP button repeatedly to quit the
setup mode.
Adjusting the level for individual speakers
(manual)
1) At step 4 above, select “Manual”, then press the
ENTER button.
2) Press the CHANNEL button or ENTER button to
select the speaker you wish to adjust.
3) Turn the Rotary encoder to adjust the output
level.
4) Repeat steps 2) and 3) above to adjust the levels
of the different speakers.
5) Press the SETUP button again to quit the setup
mode.
NOTES
• If a speaker is set to the off mode, that speaker’s level
adjustment cannot be made.
Refer to “Speaker setup” (page 22).
• Once the settings are made, we recommend storing
them in the memory. See page 28 for instructions.
RS (Right surround)
LS (Left surround)
L (Left front) C (Center)
R (Right front)
1 Press the SETUP button.
The setup mode is set.
2 Turn the Rotary encoder to select the “5.1CH
SETUP” mode, then press the ENTER buton.
3 Turn the Rotary encoder to select “REAR MIX”,
then press the ENTER button.
4 Turn the Rotary encoder to select “REAR MIX
ON” or “REAR MIX OFF”, then press the ENTER
button.
When set to “ON”, the front audio signals are
mixed into the audio signals output from the rear
speakers.
5 Turn the Rotary encoder to adjust the level,
then press the ENTER button.
The level can adjusted in five steps: –6, –3, 0, +3
and +6. The higher the level, the more bass is
output from the rear speakers. (The effect differs
according to the software (DVD, etc.).)
6 Once the settings are completed, press the
SETUP button repeatedly to quit the setup
mode.
NOTES
• This adjustment is ineffective when the rear speaker
setup setting is set to “OFF”.
• For linear PCM signals, the voice is output from the
rear speaker regardless of the REAR FILL and REAR
MIX setting.
• Once the settings are made, we recommend storing
them in the memory. See page 28 for instructions.
Mixing bass sound to the rear channel
This function mixes the front channel audio
signals to the audio signals output from the rear
speakers, improving the sound in the vehicle’s
rear seat.
NOTE
Avoid stopping, pausing, switching the disc, cueing,
fast-forwarding or switching the audio channel of the
player while making this adjustment. The setting is
canceled if the decode mode is switched.
