26-EN
Convenient Functions
Linear PCM setting
The output when playing discs recorded in linear
PCM can be set to 2 or 3 channels.
1 Press the SETUP button.
The setup mode is set.
2 Turn the Rotary encoder to select the “PCM
MODE”, then press the ENTER button.
3 Turn the Rotary encoder to select “2ch Output”
or “3ch Output”, then press the ENTER button.
2ch Output: 2ch output (L/R)
3ch Output: 3ch output (L/R/CENTER)
4 Press the SETUP button repeatedly to quit the
setup mode.
NOTE
This PCM mode is ineffective if the center speaker is set
to “OFF” or “Sub.W” in the speaker setup settings.
ENTER
SETUP
Rotary encoder
Navigation system voice guidance
interruption
When the navigation system is connected, make
the navigation system’s voice guidance
messages to interrupt the PXA-H700, then
output from the front speaker.
1 Press the SETUP button.
The setup mode is set.
2 Turn the Rotary encoder to select the “NAVI
MIX” mode, then press the ENTER button.
3 Turn the Rotary encoder to select “NAVI MIX
ON” or “NAVI MIX OFF”, then press the ENTER
button.
When ON is set, the navigation system's voice
guidance messages interrupts the PXA-H700.
4 Turn the Rotary encoder to adjust the “MIX
LEVEL” (volume level of navigation voice), then
press the ENTER button.
The level can be adjusted from 1 to 15.
5 Turn the Rotary encoder and set “GUIDE
CONT.” to “2”, then press the ENTER button.
Do not use “1”.
6 Press the SETUP button repeatedly to quit the
setup mode.
NOTE
For connection with navigation, refer to the
"Installation and Connections" (page 40).
