5. Advanced operation
5.25 G rayscal e c on versio n modes
Your Coronis Fus ion 6MP display automatically detects the connected video input
signals and applies the correct grayscale conversion settings. Manually selecting a
grayscale conversion mode is possible, but then your display’s image source selection
mode should be set to allow this. Please refer to "Image source selection modes",
page 28 to do this.
About grayscale conversion modes
Grayscale conversion modes specify how color generated on the display controller is converted to
grayscale in your display.
The available grayscale conversion modes are:
No Conversion
Use Red Channel This mode is intended for grayscale displays where
gray is sent over the red channel.
Use Green Channel This mode is intended for grayscale displays where
gray is sent over t he green channel.
Use Blue Channel This mode is in tended for grayscale di splays where
gray is sent over th e blue channel.
Use All Channels This mode is intended for grayscale di splays where
gray is sent over the red, green and blue c hannel.
This is done by mea ns of a standard conversion
mechanism where 30% red, 59% green and 11%
blue are used to generate gray.
To manually select a grayscale conversion mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > (Left/Right) Image Source menu.
3. Enter the Grayscale Conversion submenu.
4. Select one of the available color conversion modes and confirm.
5.26 EDID timings
Your Coronis Fusion 6MP display automatically detects the connected video input sig-
nals and applies the correct timings. Manually configuring t he EDID timings is possible,
but then your display’s image source selection mode should be set to allow this. Please
refer to "Image source selection modes", page 28 to do this.
About EDID t imings
Following EDID timings are available for your Coronis Fusion 6MP:
Resolution
Allows to manually modify the resolution of the
image source video input signal.
Refresh Rate Allows to manually select the refresh rate of the
image source video input signal depending on the
maximum refresh rate of the display controller
connected to your display.
Color Depth
Allows to change the color depth to 8 or to 10 bit.
30 K5902055 CORONIS FUSION 6MP 28/08/2013
