25-EN
Navigation System Operation (Optional)
Controlling Navigation System
If an optional Alpine Navigation System is
connected to the IVA-C801/CVA-1006, some of its
functions can be controlled from the IVA-C801/
CVA-1006.
The functions and display indicators available will
vary depending upon the Navigation System
connected. For details, consult your Alpine dealer.
1 Press the SOURCE button. The main menu
screen appears on the display.
2 Rotate the rotary encoder and select "NAVI,"
then press the rotary encoder to execute the
selection.
The Function Guide display changes to show the
same button names as those for the remote
control supplied with your navigation system.
NOTES
• When the V. SEL button is pressed while the
Navigation selection mode is being selected in the
VISUAL setting (refer to page 43), the navigation
mode will be directly activated.
• If the Navigation mode menu is not displayed on the
main menu screen, select "AUX IN" in the Setup mode
screen and set the Navigation mode to the ON
position.
• If you use the buttons displayed, you can control the
navigation system from IVA-C801/CVA-1006 in the
similar way to the remote control operation.
For operation, refer to the Owner's Manual for your
navigation system.
• Depending on the navigation system connected to this
unit, some functions and displays may vary.
(IVA-C801) (CVA-1006)
SOURCE
SOURCE
Rotary encoder Rotary encoder
