VRX610 2120 VRX610
2. Press the right or left side of SEARCH button
2 to automatically seek a station.
When the right side of SEARCH button 2 is
pressed, the station is sought in the direction
of higher frequencies; if the left side of
SEARCH button 2 is pressed, the station is
sought in the direction of lower frequencies.
Manual tuning
There are 2 ways available: Quick tuning and step
tuning.
When you are in the step tuning mode, the fre-
quency changes one step at a time. In quick tun-
ing mode, you can quickly tune the desired fre-
quency.
1. Press the BAND button % and select the de-
sired band. (FM or AM)
∗ If “MANU” is not lit in the display (or when the
panel is closed, if the indicator “SRCH” is lit),
press and hold the BAND button % for 1 sec-
ond or longer. “MANU” appears in the display
(or when the panel is closed, the indicator
“SRCH” goes off) and manual tuning is now
available.
2. Tune into a station.
● Quick tuning:
Press and hold the right or left side of the
SEARCH button 2 for 1 second or longer to
tune in a station.
● Step tuning:
Press the right or left side of
the SEARCH but-
ton 2 to manually tune in a station.
Recalling a preset station
A total of 24 preset positions (6-FM1, 6-FM2, 6-
FM3, 6-AM) exists to store individual radio sta-
tions in memory. Pressing the corresponding
PRESET buttons # recalls the stored radio fre-
quency automatically.
1. Press the BAND buttons % and select the
desired band. (FM or AM)
2. Press the corresponding PRESET buttons #
to recall the stored station.
∗ Press and hold one of the PRESET buttons #
for 2 seconds or longer to store that station
into preset memory.
Manual memory
1. Press the BAND button % and select the de-
sired band. (FM or AM)
2. Select the desired station with seek tuning,
manual tuning, or preset tuning.
3. Press and hold one of the PRESET buttons
# for 2 seconds or longer to store the cur-
rent station into preset memory.
Auto store
Auto store is a function for storing up to 6 sta-
tions that are automatically tuned in sequentially.
If 6 receivable stations cannot be received, a pre-
viously stored station remains unoverwritten at
the memory position.
1. Press the BAND button % and select the de-
sired band. (FM or AM)
2. Press and hold the PS/AS button 5 for 2 sec-
onds or longer. The stations with good recep-
tion are stored automatically to the preset
channels.
Preset scan
Preset scan receives the stations stored in pre-
set memory in order. This function is useful when
searching for desired station in memory.
1. Press the PS/AS button 5.
2. When the desired station is tuned in, press
the PS/AS button 5 again to continue receiv-
ing that station.
Note:
• Be careful not to press and hold PS/AS button
5
for 2 seconds or longer, otherwise the auto store
function engages and the unit starts storing sta-
tions.
Radio Operations
Radio Operations
FM reception
For enhanced FM performance the
®
tuner includes signal actuated stereo control, En-
hanced Multi AGC, Impulse noise reduction curcuits
and Multipath noise reduction circuits.
Changing the reception area
This unit is initially set to USA frequency intervals
of 10kHz for AM and 200kHz for FM. When using it
outside the USA, the frequency reception range
can be switched to the intervals below.
● Setting the reception area
While pressing DISP button
@
, each time you
press and hold the number “6” of the PRESET
buttons
#
for 2 seconds or longer, the recep-
tion area switches from inside the USA to out-
side the USA or from outside the USA to in-
side the USA.
∗ Any station preset memories are lost when the
reception area is changed.
Listening to the radio
1. Press the FUNC button 1 and select the RA-
DIO mode.
2. Press the BAND button % and select the ra-
dio band. Each time the button is pressed,
the radio reception band changes in the fol-
lowing order:
FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1...
3.
Press the right or left side of the SEARCH but-
ton
2
to tune in the desired station.
Tuning
There are 3 types of tuning mode available, seek
tuning, manual tuning and preset tuning.
Seek tuning
1. Press the BAND button % and select the de-
sired band. (FM or AM)
∗ If “MANU” is lit in the display (or when the panel
is closed, if the indicator “SRCH” is not lit) press
and hold the BAND button % for 1 second or
longer. “MANU” in the display goes off (or when
the panel is open the indicator “SRCH”
lights)and seek tuning is now available.
Instant station recall (ISR)
Instant station recall is a special radio preset that
instantly accesses a favorite radio station at a
touch of a button. The ISR function even oper-
ates with the unit in other modes.
● ISR memory
1. Select the station that you wish to store in ISR
memory.
2. Press and hold ISR button 0 for 2 seconds
or longer.
● Recalling a station with ISR
In any mode, press ISR button 0 to turn on the
radio function and tune the selected radio sta-
tion. “ISR” appears in the display. Press ISR but-
ton 0 again to return to the previous mode.
