VRX610 3534 VRX610
8. Operate the JOYSTICK ¡ rightward or left-
ward to select “MENU” and press the ENT at
the center of the JOYSTICK ¡ to change into
the AUDIO-MODE display.
Standard mode/DSF operations
DSF effect ON/OFF
∗ The factory default setting is “ON”.
1. Press the A-M button & to show the AUDIO-
MODE display.
2. Operate the JOYSTICK ¡ upward or down-
ward to select “DSF ON/OFF”. “ON” and
“OFF” items are displayed in the menu bar.
3. Operate the JOYSTICK ¡ rightward and left-
ward to select “ON” or “OFF” and press the
ENT at the center of the JOYSTICK ¡ to set
it.
Note:
• If the DSF effect is set to OFF, the adjustment
made in “DSF operations” is not reflected in the
music source.
Calling DSF BASIC Pattern/USER
Pattern
1. Press the A-M button & to show the AUDIO-
MODE display.
2. Operate the JOYSTICK ¡ upward or down-
ward to select “DSF MODE”. “BASIC 1”, “BA-
SIC 2” and “USER” items are displayed in the
menu bar.
3. Operate the JOYSTICK ¡ rightward or left-
ward to select the item thus called, and press
the ENT at the center of the JOYSTICK ¡ to
show BASIC pattern selecting display or
USER pattern selection/memory display.
4. In the pattern selecting display, operate the
JOYSTICK ¡ rightward or leftward to select
P1 to P6, and press the ENT at the center of
the JOYSTICK ¡ to call corresponding DSF
mode. In this display, pressing the No. button
in correspondence to the PRESET buttons #
can also call the DSF mode.
∗ After selecting P1 to P6 by operating the JOY-
STICK ¡, press the ENT at the center of the
JOYSTICK ¡ for 2 seconds or longer to copy
the selected pattern to the USER pattern.
∗ Operate the JOYSTICK ¡ rightward or left-
ward to select “EDIT”, and press the ENT at
the center of the JOYSTICK ¡ to show DSF
adjusting display, in which the properties of cur-
rently selected pattern can be adjusted.
DSP operations
∗ By pressing the BAND button % in BASIC pat-
tern selecting display or USER pattern selec-
tion/memory display you can switch between
the two patterns, BASIC and USER.
5. Operate the JOYSTICK ¡ rightward or left-
ward to select “MENU”, and press the ENT at
the center of the JOYSTICK ¡ to return to
the AUDIO-MODE display.
Setting and storing DSF Properties/
Memory into USER Pattern
1. Repeat the steps 1 to 3 of the previous proce-
dure (Calling DSF BASIC Pattern/USER Pat-
tern) to show BASIC pattern selecting display
or USER pattern selection/memory display.
2. Operate the JOYSTICK ¡ upward or down-
ward to select “EDIT”, and press the ENT at
the center of the JOYSTICK ¡ to show the
DSF adjusting display.
3. Select an item to be adjusted by operating the
JOYSTICK ¡ rightward or leftward in the DSF
adjusting display.
“EF” ➜ EFFECT
“DL” ➜ DELAY
“R.M” ➜ REAR MIX
“R.S” ➜ ROOM SIZE
“LV” ➜ LIVENESS
“R.T” ➜ REVERB TIME
“HI” ➜ HIGH
4. Operate the JOYSTICK ¡ upward or down-
ward to set each adjusting value.
∗ By pressing the PRESET buttons # once in
the DSF adjusting display, the setting value for
currently stored USER pattern is obtained.
5. After making adjustments to a desired pattern
by repeating the operations of items 3 and 4,
operate the JOYSTICK ¡ rightward or left-
ward to move the cursor to “RTN”, and press
the ENT at the center of the JOYSTICK ¡ to
change over to the BASIC/USER pattern se-
lection/memory display.
6.
Operate
the JOYSTICK ¡ rightward or left-
ward
in the BASIC/USER pattern selection/
memory display to select USER memory P1 to
P6 to be stored, and press
the ENT at the cen-
ter of the JOYSTICK ¡
for 2 seconds or longer
to store the adjusted DSF pattern to the USER
memory.
∗
By pressing the PRESET buttons # 1 to 6 for 2
seconds or longer in the DSF adjusting display, the
DSF pattern can be stored in the USER memory.
Standard mode/G.EQ opera-
tions
Note:
• The adjustment made in standard mode is not re-
flected in the adjustment in professional mode. Re-
spectively, the adjustment made in professional mode
is not reflected in the adjustment in standard mode.
G.EQ effect ON/OFF
∗ The factory default setting is “ON”.
1. Press the A-M button & to show the AUDIO-
MODE display.
2. Operate the JOYSTICK ¡ upward or down-
ward to select “EQ ON/OFF”. “ON” and “OFF”
items are displayed in the menu bar.
3.
Operate the JOYSTICK ¡ rightward or leftward
to select “ON” or “OFF” and press the ENT at
the center of the JOYSTICK ¡ to set it.
4. After the setting, press the A-M button &
again to return to the STANDARD display.
Note:
• If the G.EQ effect is set to OFF, the adjustment
made in “G.EQ operations” is not reflected in the
music source.
Calling G.EQ BASIC Pattern/USER
Pattern
1. Press the A-M button & to show the AUDIO-
MODE display.
2. Operate the JOYSTICK ¡ upward or down-
ward to select “EQ MODE”. “BASIC” and
“USER” items are displayed in the menu bar.
3. Operate the JOYSTICK ¡ rightward or left-
ward to select the item thus called, and press
the ENT at the center of the JOYSTICK ¡ to
show BASIC pattern selecting display or
USER pattern selection/memory display.
4. In the Pattern selecting display, operate the
JOYSTICK ¡ rightward or leftward to select
P1 to P6, and press the ENT at the center of
the JOYSTICK ¡ to call corresponding G.EQ
pattern. In this display, pressing the No. but-
ton in correspondence to the PRESET button
# can also call the G.EQ pattern.
∗ After selecting P1 to P6 by the JOYSTICK ¡,
press ENT at the center of the JOYSTICK ¡
for 2 seconds or longer to copy the selected
pattern to the USER pattern.
∗ Operate the JOYSTICK ¡ rightward or leftward
to select “EDIT”, and press the ENT at the cen-
ter of the JOYSTICK ¡ to show G.EQ adjust-
ing display, in which the properties of currently
selected pattern can be adjusted.
∗ By pressing the BAND button % in BASIC pat-
tern selecting display or USER pattern selec-
tion/memory display you can switch between
the two patterns, BASIC and USER.
5. Operate the JOYSTICK ¡ rightward or left-
ward to select “MENU”, and press the ENT at
the center of the JOYSTICK ¡ to return to
the AUDIO-MODE display.
Setting and storing G.EQ Proper-
ties/Memory into USER Pattern
1. Repeat the steps 1 to 3 of the previous proce-
dure (Calling G.EQ BASIC Pattern/USER Pat-
tern) to show BASIC pattern selecting display
or USER pattern selection/memory display.
2. Operate the JOYSTICK ¡ leftward and right-
ward to select “EDIT”, and press the ENT at
the center of the JOYSTICK ¡ to show the
G.EQ adjusting display.
3. When some frequency to be adjusted is se-
lected by operating the JOYSTICK ¡ right-
ward or leftward in the G.EQ adjusting display,
a gain setting value at the selected frequency
is displayed.
4. Operate the JOYSTICK ¡ upward or down-
ward to adjust the G.EQ GAIN.
∗
By pressing the
PRESET buttons #
once in the
G.EQ adjusting display, the setting value for cur-
rently stored USER pattern is obtained.
5. After making adjustments to a desired pattern
by repeating the operations of items 3 and 4,
operate the JOYSTICK ¡ rightward or left-
ward to move the cursor to “RTN”, and press
the ENT at the center of the JOYSTICK ¡ to
change over to the BASIC/USER pattern se-
lection/memory display.
6.
Operate the
JOYSTICK ¡
rightward or leftward
in the BASIC/USER pattern selection/memory
display to select USER memory P1 to P6 to be
stored, and press
the ENT at the center of the
JOYSTICK ¡
for 2 seconds or longer to store
the adjusted G.EQ pattern to the USER memory.
∗ By pressing the PRESET button # 1 to 6 for 2
seconds or longer in the G.EQ adjusting dis-
play, the G.EQ pattern can be stored in the
USER memory.
7. To set a title of the stored USER pattern, op-
erate the JOYSTICK ¡ rightward or leftward
to select “TITLE” and press the ENT at the
center of the JOYSTICK ¡ to change into the
Title Input display.
∗For title inputting method, refer to the section
“Entering titles”.
DSP operations
