Technical Specification
Parameter Specification
Symbol rate step 1 Symbol/s
Symbol rate lock range
± 100 ppm
Maximum Channel bit-rate 90 Mbps
Maximum user bit-rate 81 Mbps
Es/No (C/No) ratio See Table B.12
Constellation Output
3
Availability RX1290/HWO/DVBS2/IF/CONST only
Safety status SELV
Number of outputs 2 (I and Q)
Output connector type
BNC, female 75 Ω
Output impedance
75 Ω
Miscellaneous
DVB-S Phase noise
tolerance4
SSB phase-noise power spectral density < -68 –
10*log(Rs/20) dBc/Hz at δF = 10 kHz offset
Phase noise power spectral density of the form C –
20*Log(δF)
δF = Frequency offset from carrier
Rs = Symbol-rate (Msymbol/s)
DVB-S2 Phase noise
tolerance5
-25 dBc/Hz at δF = 100 Hz
-50 dBc/Hz at δF = 1 kHz
-73 dBc/Hz at δF = 10 kHz
-93 dBc/Hz at δF = 100 kHz
-103 dBc/Hz at δF = 1 MHz
-114 dBc/Hz at δF > 10 MHz
LNB power and control See Table B.13
Table B.11 shows the Eb/No requirements for DVB-S and Table B.12 for DVB-S2
Es/No requirements to ensure error-free demodulation for all supported FEC rates.
3
Enabling this feature disables output transport stream and renders the receiver unable to decode a service. Operational for DVB-S2 modes
only.
4
These specifications apply in the presence of thermal noise at the threshold Eb/N
0
ratio given in Table B.11
5
These specifications apply in the presence of thermal noise at the threshold Es/No ratio given in Table B.12 and assume a degradation to
the thermal noise performance of 0.3 dB.
