Table C.4 Input Selection Menu
Display Title: Input Description
Select XXXX
XXXX is the editable input source selection (ASI, SMPTE 310,
any option cards).
C.5.3 DVB-S2 Option
DVB-S2 Input Option (RX1290/HWO/DVBS2 or
RX1290/HWO/DVBS2/IF/CONST)
When a DVB-S2 interface is used, the Input menu allows the user to edit the
parameters.
Table C.5 DVB-S2 Input Menu
Display Title: Input Description
Input Quality
BER
1
XX
C/N YY
C/N Margin ZZ
XX is the signal quality expressed as BER
YY is the estimated carrier to noise ratio in dB
ZZ is the estimated carrier to noise ratio margin to failure in dB
Input Select
Source XX
XX is 1, 2 3 or 4 for RX1290/HWO/DVBS2
XX is 1,2,3, IF for RX1290/HWO/DVBS2/IF/CONST
Input LNB Frequency RR
Satellite Frequency SS
Symbol Rate TT
Modulation UU
Roll-off VV
Search Range WW
Mode XX
2
LNB Power YY
LNB 22 kHz ZZ
RR is the LNB FREQUENCY in MHz
SS is the SATELLITE FREQUENCY in MHz
TT is the SYMBOL RATE in Msym/s
UU is the MODULATION Standard (DVB-S or DVB-S2)
VV is the spectral ROLL-OFF (35%, 25%, 20%)
WW is the SEARCH Range in kHz
XX is the constellation output mode (NORMAL or CONSTELLATION)
YY is the LNB POWER (ON, OFF or BOOSTED)
ZZ is ENABLE/DISABLE
C.5.4 TTV G.703 (DS3 and E3) Option Menu
When a TTV G.703 input interface is used, the Input menu allows the user to edit
the set-up parameters
1
BER is Post Viterbi BER for DVB-S, Packet Error Ratio for DVB-S2
2
TT1260/HWO/DVBS2/ASI/IF/C option only. Enabling CONSTELLATION Mode renders the receiver unable to decode a service.
