Display Controller Installation
26
Figure 3: Power connection for the MXRT 5100 and 7100 controllers
Figure 4: Power connection for the MXRT 7200 controller
9. Screw in or fasten the display controller securely. Replace and
secure the computer cover.
10. Connect your B
ARCO NIO FUSION Displays to the display
controller(s) for your B
ARCO NIO FUSION Display System using the
cables supplied. Make sure all cables are securely connected
6-pin graphics controller
power cable
6-pin graphic controller
power cables - connect
2 cables as shown
