Display parts, controls and connectors
35
1. Connector compartment cover.
Detach to get access to the signal connectors.
2. Slots for security cable (e.g., Kensington lock).
3. (Not visible on drawing) Push-button to release the panel unit
from the display stand. This button is located on the rear of the
panel. You must release the panel unit from the display stand in
case you wish to attach the panel unit to a VESA mount stand.
4. Display stand neck cover. Detach it before connecting the signal
cables to route the cables neatly.
5. Cable duct covers. Push them down and open them before
connecting the signal cables to route the cables neatly.
6. Push-button to unlock the display height adjust mechanism.
When the display is shipped, the display height mechanism is
locked to prevent damage during shipping. To unlock the
mechanism and adjust the display height, press the push-button
while pushing down the display panel. Then slowly release the
display panel.
