8-7
W106 Rev 1.5
X20 Console Manual
Procedure of Auto Shutdown, When ‘Disabled’
If the ‘Enable Auto Shutdown’ is deselected (no tick in box) OR
the X20 Manager program is not running in the background then
the X20 Manager will not be activated, when the external supply
voltage drops below the 10.8 Volt threshold.
In this situation the X20 console’s Power Management ATX
hardware takes over:
The Status LED for the external supply (left LED) will turn 1.
RED
The 2. default time delay for the ATX hardware is 60 seconds
Therefore if the external supply voltage stays below the 3.
10.8 Volt threshold for more than 60 seconds then an ATX
Shutdown will be started
Once the 60 seconds has been reached then both Status 4.
LED's will flash indicating the X20 console is shutting
down
Windows5.
®
will start shutting down all ATX compliant
programs and save data, then Windows
®
operating system
will start shutting down and will save all data and then the
X20 console will turn OFF.
