9-EN
Display example for FM Radio main screen
[DX SEEK]*
1
button: Displays the tuning mode selection
list.
Displays the preset number*
2
/frequency
*
1
The button displays the current tuning mode.
*
2
Displayed only when the current station is the preset one.
This unit cannot receive HD Radio signals (digital terrestrial radio). In
order to activate the digital radio functions described below, an optional
HD Radio Tuner module must be connected through the Ai-NET bus.
Listening to the Radio
HD Radio signals can be received if the HD Radio TUNER MODULE
is connected. While receiving HD Radio signals, the unit can
automatically switch between the analog and digital signal.
1
Press SOURCE to activate mode switching
screen.
2
Slide the display horizontally with your finger to
select Audio/Visual mode.
Each time you slide the display, the mode switches
circularly in the following order:
Audio/Visual Navigation Camera Telephone
Multi Info Audio/Visual
3
Slide the display vertically with your finger, or press
SOURCE repeatedly to select RADIO or HD
RADIO*
3
source.
4
Touch the RADIO or HD RADIO source window
displayed in the center of the screen.
The RADIO or HD RADIO source is activated and the
display changes to the RADIO or HD RADIO main screen.
*
3
The digital radio can be received if the optional HD Radio Tuner
module TUA-T500HD or TUA-T550HD is connected.
5
Touch [BAND] to select the desired radio band.
Each press changes the bands as follows:
6
Touch [DX SEEK] to choose the tuning mode.
• There are two modes you can select for auto tuning, DX and
Local:
- DX (Distance) mode ;
Both strong and weak stations will be tuned in.
- Local mode ;
Only strong stations will be tuned in.
The initial setting is DX.
7
Touch [ ], [ ] or [ ], [ ] to change the
radio frequency up or down respectively.
In manual mode, touch and hold to change the frequency
continuously.
Presetting Stations Manually
1
Tune in a desired radio station you wish to store in
the preset memory by manual or automatic seek
tuning.
2
Touch [PRESET] to display the list screen of preset
stations.
3
Touch and hold any one of the preset stations
(1 through 6) for at least 2 seconds.
The current station is stored.
4
Repeat the procedure to store up to 5 other stations
onto the same band.
To use this procedure for other bands, simply select the
desired band and repeat the procedure.
A total of 18 stations can be stored in the preset memory
(6 stations for each band; FM1, FM2 or AM).
• Touch [ ] to cancel the list screen of preset stations.
• If a preset memory has already been set in the same preset number, it
will be cleared and the new station will be memorized.
Radio
FM-1 FM-2 AM FM-1
DX SEEK LOCAL SEEK MANUAL
