44-EN
When the optional rearview camera HCE-C107D is connected, rearview
video can be output to the monitor.
Be sure to set “Camera IN” to DIRECT before using the rearview
camera HCE-C107D, refer to
“Setting the Rear Camera Input”
(page 20).
Switching the Rear Camera Screen
(Optional)
The rear view video will be displayed for the two situations as below.
1
Shift the gear lever to the reverse (R) position.
The rear view image is displayed while the car remains in
reverse.
2
If you shift the gear lever to a position other than
reverse (R), the monitor returns to the previous
screen.
Be sure to also check behind the car visually. Use the camera image
to assist in showing conditions behind the car.
This function is effective when the reverse wire is properly connected.
Select “Camera” in mode switching screen, and the rearview image
from HCE-C107D is displayed. For details, refer to step 1-2 of
“Recalling the Source” on page 8.
Switching the Navigation Screen
(Optional)
If an optional Alpine Navigation System is connected to the iXA-W407,
the Navigation screen can be displayed on this unit.
Be sure to set “NAV. IN” to ON before using the navigation, Refer to
“Setting the Navigation Mode” on page 20.
Press /VISUAL.
The Navigation screen is displayed.
Pressing again will return to Audio/Visual mode.
The operation is possible with the supplied navigation remote
control.
For navigation operation, refer to the Owner’s Manual of the
navigator.
The Navigation mode can also be activated by selecting
“Navigation” in mode switching screen. For details, refer to the step
2 of
“Recalling the Source” on page 8.
If the Navigation mode menu is not displayed on the main menu
screen, select ON in
“Setting the Navigation Mode” on page 20.
When the Navigation System is on and in guidance mode, the voice
prompts and navigation map interrupts the current audio source.
HCE-C107D
Operation (Optional)
Displaying the rear view video while the
car is in reverse.
Displaying the rear view video manually
Navigation System
(Optional)
