Radio Antenna Receptacle
Video Input Connector (AUX INPUT) (Yellow)
Input the video.
Audio Input Connectors (AUX INPUT)
RED is right and WHITE is left input the audio.
Video Input Connector (AUX INPUT) (Yellow)
Input the video.
Audio Input Connectors (AUX INPUT)
RED is right and WHITE is left input the audio.
Video Output Connector (AUX OUTPUT) (Yellow)
Output the video.
Audio Output Connectors (AUX OUTPUT)
RED is right and WHITE is left output the audio.
Rear Output/Input RCA Connectors
It can be used as Rear Output or Input RCA Connectors.
Front Output/Input RCA Connectors
It can be used as Front Output or Input RCA Connectors.
Subwoofer RCA Connectors
RED is right and WHITE is left.
RCA Extension Cable (sold separately)
Remote IN/OUT Connector
Remote Control Output Lead (White/Brown)
Connect this lead to the remote control input lead. This lead
outputs the controlling signals from the remote control.
Remote Control Output Lead (White/Brown)
Connect this lead to the remote control input lead. This lead
outputs the controlling signals from the remote control.
Remote Control Input Lead (White/Brown)
Connect the external Alpine product to the remote control
output lead.
Reverse Lead (Orange/White)
Use only when a back-up camera is connected. Connect to
the plus side of the car’s reverse lamp. This lamp illuminates
when the transmission is shifted into reverse (R).
With this lead properly wired, the video picture
automatically switches to the back-up camera whenever the
car is put into reverse (R).
Monitor Control Lead (White/Pink)
Connect this to the Monitor Control Lead of the touch panel-
compatible rear monitor.
iPod AUDIO/VIDEO Input Connector
Connect this to the AV extension cable.
Steering Remote Control Interface Connector
To steering remote control interface box.
For details about connections, consult your nearest Alpine
dealer.
MIC Input Connector
To Microphone (supplied).
RGB Input Terminal
Connect this to the RGB output terminal of the Navigation
System.
CAMERA Input RCA Connector
Use when connecting a back-up camera with RCA Output
Connector.
USB Connector
Ai-NET Connector
Connect this to the output or input connector of another
device (CD Changer, Equalizer, HD Radio
TM
TUNER
MODULE, etc.) equipped with Ai-NET.
• You can input TV/video sound by connecting an optional
Ai-NET/RCA Interface cable (KCA-121B) to this component.
• Be sure to set “Setting the Connected Head Unit (MODEL SETUP)”
to “DVD CHG”, when the DHA-S690 is connected.
Direct CAMERA Input Connector
Use when the optional rearview camera HCE-C107D is
connected.
Power Supply Connector
System Switches
When connecting an equalizer or divider using Ai-NET
feature, place the two switches in the EQ/DIV position.
When no device is connected, leave the switches in the
NORM position.
• Do not make the two switches to different settings.
• Be sure to turn the power off to the unit before changing the switch
position.
24 PIN pre-out/AUX-I/O Connector
Ai-NET Cable (Included with CD Changer)
Remote Turn-On Lead (Blue/White)
Connect this lead to the remote turn-on lead of your
amplifier or signal processor.
Power Antenna Lead (Blue)
Connect this lead to the +B terminal of your power antenna,
if applicable.
• This lead should be used only for controlling the vehicle’s power
antenna. Do not use this lead to turn on an amplifier or a signal
processor, etc.
Audio Interrupt In Lead (Pink/Black)
Parking Brake Lead (Yellow/Blue)
Connect this lead to the power supply side of the parking
brake switch to transmit the parking brake status signals to
the iXA-W407.
Foot Brake Lead (Yellow/Black)
Connect to the vehicle’s foot brake lead or brake lamp lead.
Switched Power Lead (Ignition) (Red)
Connect this lead to an open terminal on the vehicle’s fuse
box or another unused power source which provides (+)
12V only when the ignition is turned on or in the accessory
position.
Battery Lead (Yellow)
Connect this lead to the positive (+) post of the vehicle’s
battery.
Fuse Holder (10A)
Ground Lead (Black)
Connect this lead to a good chassis ground on the vehicle.
Make sure the connection is made to bare metal and is
securely fastened using the sheet metal screw provided.
Right Front (+) Speaker Output Lead (Gray)
Right Front (–) Speaker Output Lead (Gray/Black)
Right Rear (–) Speaker Output Lead (Violet/Black)
Right Rear (+) Speaker Output Lead (Violet)
Left Rear (+) Speaker Output Lead (Green)
Left Rear (–) Speaker Output Lead (Green/Black)
Left Front (–) Speaker Output Lead (White/Black)
Left Front (+) Speaker Output Lead (White)
USB extension cable (Included)
AV extension cable (Included)
USB 30P cable (Included)
