21-EN
Adjusting the AUX name Mode
Adjusting the AUX1 name
After setting AUX1 IN to ON in “Setting the AUX Mode”, this setting
can be carried out.
Setting items: Primary
/ Secondary
*
1
Setting contents: OFF
*
2
/ AUX
*
3
/ DVD / GAME / TV / EXT.DVD /
NAV. / DVD CHG / USB Video
*
3
*
1
When a USB Video box (sold separately) is connected, you can use it
to connect one more External Input device. Setting the Secondary
name can change the source name display of this device.
*
2
The setting is only available for Secondary.
*
3
The setting is only available for Primary.
• The selected source name is displayed instead of AUX source name.
• Second name can be set only when Primary name is set to USB
Video.
• Only when an Alpine TV tuner is connected, you can operate the
displayed function guide from this unit.
• When AUX1 and AUX2 are set to the same name, “1” and “2” will
be added after the names, e.g. DVD1, DVD2.
Adjusting the AUX2 name
After setting AUX2 IN to ON in “Setting the AUX Mode”, this setting
can be carried out.
Setting item: Name
Setting contents: AUX / DVD / GAME / TV / EXT.DVD / NAV. /
DVD CHG / USB Video
• The selected source name is displayed instead of AUX source name.
• When AUX1 and AUX2 are set to the same name, “1” and “2” will
be added after the names, e.g. DVD1, DVD2.
• When you connect a DVD changer via Ai-NET connector to this unit,
the name of AUX2 will fix to “DVD CHG”.
Adjusting the External Input Audio Level
After setting to ON in “Setting the AUX Mode”, this setting can be
carried out.
Setting item: Level
Setting contents: LOW / HIGH
Switching the Visual Input Signal System
After setting to ON in “Setting the AUX Mode”, this setting can be
carried out.
Setting item: Signal
Setting contents: NTSC / PAL / AUTO
• The video input type can be changed.
• When set to AUTO, unstable display may occur while playing back
certain black and white video signal. In this case, select NTSC or
PAL mode manually.
Outputs the picture of the source selected on the iXA-W407 connected
to the rear monitor.
Setting item: AUX OUT
Setting contents: OFF / ON
Setting item: Bluetooth IN
Setting contents: OFF / BUILT-IN / NAV.
• For details on BLUETOOTH operation, refer to “BLUETOOTH
Operation” on page 39.
• If the mobile phone compatible with the Voice Dial function is
connected, the Voice Dial function can be used.
If a USB Adapter is to be used, set to ON.
Setting item: USB Adapter
Setting contents: OFF / ON
• If ON is set even when a CD changer is connected the source name
on the Audio/Visual source selection screen will change from CD
CHG. to USB.
The unit’s /VISUAL (OPTION) button function can be changed.
Setting item: Option Key
Setting contents: TEL / SAT / TAGGING
LOW: Decreases the external input audio level.
HIGH: Increases the external input audio level.
Setting the Picture Output
OFF: The “RSE” item cannot be activated on the mode
switching screen.
ON: The “RSE” item can be activated on the mode switching
screen.
Touch [RSE] to change to the Rear selection screen, and
then touch the desired source. The selected source
picture is output on the rear monitor.
Setting the BLUETOOTH Connection
(Bluetooth IN)
OFF: Select to ignore any external interrupts.
BUILT-IN:
Set the built-in BLUETOOTH function to ON.
The TEL screen of the BLUETOOTH is displayed.
When an external interruption occurs, the display
changes to the TEL screen.
NAV.: Select when the optional portable navigation is
connected.
The TEL screen of the portable navigation is
displayed.
Setting the USB Adapter to ON/OFF
OFF: Does not display the USB source name on the Audio/
Visual source selection screen.
ON: Displays the USB source name on the Audio/Visual
source selection screen.
Setting the OPTION Button on the Unit
TEL: Press and hold /VISUAL(OPTION) for at least 2
seconds, the BLUETOOTH TEL screen will be
recalled.
SAT: Press and hold /VISUAL(OPTION) for at least 2
seconds. When either the XM or SIRIUS Receiver Box
is connected, the Weather or Traffic channels will be
recalled.
TAGGING:
If you press and hold /VISUAL(OPTION) for at least
2 seconds when a tagging compatible HD Radio
module is connected, music tags are stored. With a
compatible iPod connected, tags are transferred to to
it for syncing to a computer. For details, refer to Radio
on page 9.
