Chapter 2: Basic Checkout
Status Tab
28 Psion Teklogix 8515 Vehicle-Mount Computer User Manual
2.9.4 Status Tab
Figure 2.16 SCU Status Menu
The Status tab provides status information including IP address and MAC address for the
client radio, IP address and MAC address for the AP, signal strength, channel, transmit
power and data rate.
2.9.5 Diags Tab
Figure 2.17 SCU Diagnostics Menu
Use the Diags tab as a troubleshooting tool. The functions are as follows:
TX Diversity Defines how to handle antenna
diversity when transmitting data
to AP.
-Main only: Use main
antenna only.
-Aux only: Use auxiliary
antenna only.
-On: Use diversity.
On
WMM Use Wi-Fi Multimedia Exten-
sions, also know as WMM.
On, Off Off
Table 2.3 Global Settings Menu
Global Setting Description Value Default
Ping Address
Ping Results
