Chapter 4: Windows Embedded CE 5.0
Using A Dialog Box
Psion Teklogix 8515 Vehicle-Mount Computer User Manual 59
Warm Reset
The Warm Reset option resets the 8515, leaving all saved files and (registry) settings intact.
Any unsaved data is lost.
Cold Reset
The Cold Reset option resets the 8515. Any files not stored in permanent memory are lost.
However, the registry settings are saved.
4.5 Using A Dialog Box
A dialog box (like those in the sample screens in Figure 4.14 on page 59) appears when you
need to make selections and enter further information.
Figure 4.14 Navigating Dialog Boxes
Note: A dialog box item that is displayed in grey text indicates that it is not
currently available.
Checkbox
Dropdown Menu Button
Te xt bo x
Radio Button
Ta bs
