Barco - RHDM-2301 - User manual 121
Full functionality description
4.3.5.3 Dual link 1-AB menu
•
Measured standard link A:
the standard measured by the display unit on link A.
•
Identifier packet link A:
the packet with standard information identified by the display unit on
link A.
•
Measured standard link B:
the standard measured by the display unit on link B.
•
Identifier packet link B:
the packet with standard information identified by the display unit on
link B.
•
Use packet Identifier:
Here one can choose whether the packet identifier needs to be used for
signal detection or not. It can be unchecked in case the source gives a wrong identifier. This can
be the case when manufacturers do not use the correct standard.
To display the video information on the screen, the display unit gives priority to the standard it
detects by analyzing the input signal. If the identifier packet does not correspond to the measured
standard, or if the video signal is not displayed properly due to a wrong measurement of the
standard, it is possible to force the display unit to show the video signal according to manual
settings by checking the “Override signal detection” option.
automatic detection of the input signal
input signal is set manual: override signal detection is checked
