Barco - RHDM-2301 - User manual 187
Addendum
• Screening: Silkscreening (ALU RAL 9006)
Back
• Priming coat: 2-component epoxy primer
• Top coat: 2-component purethane paint
• Color: Black RAL9005
• Screening: Silkscreening (white)
7.1.3 Environmental specifications
7.1.3.1 Random vibration
• Barco Truck simulation procedure for random vibrations - 1gRMS / 10-500Hz for all three axes
7.1.3.2 Functional shock
Operating:
• 25 g – 6 ms
• 3 axes – 1000 shocks per axes
Test: Unit is under power during shock; shocks do not damage the unit
7.1.3.3 Temperature
7.1.3.3.1 Storage temperature
• High temp.: +70°C (+158°F)
• Low temp.: -30°C (-22°F)
7.1.3.3.2 Operating temperature
• High temp.: +40°C (+104°F)
• Low temp.: +10°C (50°F)
7.1.3.4 EMI/EMC
7.1.3.4.1 EMI/EMC notice
The unit meets the following specifications when mounted in test console (to reflect the real
application). Internally in the console, a sealed power supply cable is used to connect the unit to
the console connector. Also internally in the console, the signal cables will be unshielded.
Externally, the power cable will be unshielded and the signal cables shielded.
Network cables (ethernet, tally) should be shielded to meet the specifications.
