7.1.1.4 Connectors
7.1.1.4.1 Input and output options
1 SDI input board 11 Ethernet RJ45 (2 ports)
2 SDI input board (optional) 12 24 Vdc in
3 Optional slot 13 100 – 240 Vac in
4 Optional slot 14 Earth stud
