First operation
2 First operation
2.1 Unpacking, installation and cabling
For unpacking, installation and cabling please refer to:
• The quick installation sheet
• The section “Installation” in the Addendum
NOTE
:
The display unit is almost fully mounted when unpacked. Do not forget to connect the power and USB cable
between the display unit and the control panel.
2.2 Overview locations for operation
Figure 1: Overview of operational controls, indicators and OSD functionalities
5
6
1
3
2
4
